Name: Waterproof IP65 18w 36w 45w LED Tri Proof Lamp PC Aluminum Material
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: DR-TP040-BG701
Availability: InStock

Home Products LED Moisture-proof Lamp

Waterproof IP65 18w 36w 45w LED Tri Proof Lamp PC Aluminum Material

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	DUALRAYS(OEM available)
Certification:	CE, ROHS, TUV/GS, LM79, LM80
Model Number:	DR-TP040-BG701

Payment & Shipping Terms:

Minimum Order Quantity:	2PCS
Price:	Please inquiry for latest price
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	5-15 bussiness days
Payment Terms:	L/C, T/T, Western Union, paypal
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Input Voltage:	AC100-277V 50/60Hz	Power Factor:	0.98
Efficiency:	120/160lm/W	IP Rating:	IP65
Led Source:	EPISTAR	Material:	PC Aluminum
CCT:	WW:3000±200K NW: 4000±200K DW:5000±200K CW: 5700±200K	Liafe Spand:	>50,000 H
Warranty:	5-10 Years	UGR:	<22
Application:	WAREHOUSE, Supermarket, Parking Lot, Industrial, Supermarket So On
Highlight:	45w LED Tri Proof Lamp , 18w LED Tri Proof Lamp , 36w Tri Proof LED Batten

Waterproof IP65 18w 36w 45w LED Tri Proof Lamp PC Aluminum Material

IP65 High Quality Good Selling PC+aluminum 18w 36w 45w led tri-proof batten light waterproof led tube

> Highly brightness EPISTAR/SAN‘AN SMD2835 LEDs,energy efficient - up to 160 lm/w;

> 1-10V dimming flicker-free driver;

> Single or Double wiring;

> IP66 and IK10 for all industrial areas of application;

> Eco full plastic light design,save your cost and freight;

> Multiple Link with double wiring;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> Over 5 years warranty life span, durable and economical;

Options:

> Driver and LED light source:

> Controls and Dimming: Zigbee wireless control / 1-10V Dimming / Daylight sensor,microwave sensor,CCTadjustable,emergency.

> Plug : European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable optional.

> Installation: Suspension, Ceilign Mounted and adjustable surface mount.
> Single or double wiring and connection.

> Customized supported for special projects.

Model No.	DR-TP020-BG2XPX	DR-TP030-BG4XPX	DR-TP040-BG4XPX	DR-TP040-BG5XPX	DR-TP050-BG5XPX
System Watts/W	20W	30W	40W	40W	50W
System Efficiency/LPW	120LPW / 140LPW Optioanl
Lumen Output/lm	2.400/2.800±5%	3.600/4.200±5%	4.800/5.600±5%	4.800/5.600±5%	6.000/7.000±5%
Rated Input Voltage/V	AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
LEDs Light Source	SMD2835
SDCM	<6
CCT/K	5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra	>80Ra (>70Ra for Option)
Power Factor	>0.94
THD	<10%
Beam Angle(Optional)	120°
UGR	<22
LED Driver	DUALRAYS Own Developed High PF Interior Driver
IP Rating	IP65
IK Level	IK08
Dimming(Optional)	1-10V
Sensor(Optional)	No
Emergency(Optional)	No
Protection Class	ClassⅠ
Finishing Color(Optional)	White RAL9016 Optional
Material	PC+PC
Lifespan/hrs	50.000 Hrs (Ta=30℃@L70)
Operation Temp/℃	40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃	- 40°C to + 65°C(-40°F to 149°F)
Installation(Optional)	Suspension / Ceiling Mounting Optional
Certificate	CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

* Replacement for fluorescent NCF

* Workshops and warehouse

* Garage and car parks

* Sport facility

* Corridor/Gallery/Corridor

* Outdoor & Indoor Locations

Character/Length	2ft	4ft	5ft
A	600mm	1200mm	1500mm
B	74mm	74mm	74mm
C	74m	74mm	74mm

(I) Emergency Function

Q1: What is the warranty? What service can I get during this period?

RE: For the D2 Series LED triproof light,Dualrays provide 5 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

Q2: What are the applications of your D2 tri-proof light?

RE:Our street light can be applied in Replacement for fluorescent NCF

* Workshops and warehouse

* Garage and car parks

* Sport facility

* Corridor/Gallery/Corridor

* Outdoor & Indoor Locations, etc.

Q3: Can I start from 1pcs sample?

RE: Yes, 1pcs sample order for testing welcomed. Dularays make effort to support every customer.

Q4: What is the production time normally?

RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.

Q5: Can you do DIAlux Simulation?

RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website or inquire us to send.

Q6: Do you offer smart controllers?

RE: Yes, please contact us for details.

Q7: What’s the payment methods you can accept ?

RE: We can accept multi payment routes in order to be more flexible and convenient for our customers all over the world,Western Union,Paypal,T/T,L/C.But generally the standard payment method is T/T for bulk orders,30% T/T in advance,balance 70% before shipment The bank information is written in the PI.

Q8: What‘re the chips and drivers used?

RE: High brightness San‘an SMD2835 LEDs light source,BOKE flicker free drivers for standard configuration.

Q9: What is the beam angle?

RE: 120°

Q10: What’s your shipping method ?

RE: UPS, DHL, Fedex, TNT or Shipping by Air,by train(for Europe) or by sea for option.

Q11: Labeling ?

RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

Q12: Finish color?

RE: Standard colors: Silver,other colors can be customized, based on MOQ 50PCS.

Q13: Dimming functions?

RE: PIR sensor,Emergency,1-10V,DALI,Microwave sensor is available.

Welcome to contact us for more information.
