100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard

  • 100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard
  • 100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard
  • 100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard
  • 100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard
100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard
Product Details:
Place of Origin: Shenzhen, China
Brand Name: DUALRAYS
Certification: CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number: DR-FL100-CGXX
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 Bussiness Day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50000PCS/Month
Contact Now
Detailed Product Description
AC Input Vol: AC100~240V 50/60Hz CCT/K: 3000K-6500K
Driver: Meanwell/Sosen Warranty: 5 Years Guarantee
Material: AL+PC Rated Power: 100W
High Light:

waterproof led flood lights

,

led yard flood lights

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 0
100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 1

Options:
> Driver: Sosen,Meanwell ELG/HLG driver;
> Controls and Dimming: 1-10V, DALI,PWM,Zigbee;
> Surge Protection Device: Meanwell SPD-20 20KV Surge Protector;
> Lens : Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV;
> Microwave Motion Sensor;

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 2
> Airports & Harbors
> Billboard illumination
> Large recreational sports facilities
> Industrial areas & Landscape buildings
> Roundabouts and motorway junctions

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 3
Model No.
DR-FL050-CGXX DR-FL100-CGXX DR-FL150-CGXX DR-FL200-CGXX DR-FL300-CGXX
System Watts/W
50W 100W 150W 200W
300W
System Efficiency/LPW
120~125LPW
Lumen Output/lm
6.500±5% 12.500±5% 18.750±5% 25.000±5% 37.500±5%
Rated Input Voltage/V
AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
LEDs Light Source
SMD3030
SDCM
<5
CCT/K
5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra
>70Ra (>80Ra for Option)
Power Factor
>0.95
THD
<10%
Beam Angle(Optional)
Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV beam angle optional
UGR
<25
Surge Protection
6~10KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver
Sosen,Meanwell ELG / HLG Optional
IP Rating
IP65
Dimming(Optional)
1-10V, DALI,PWM,Zigbee for Option
Safety Protection Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Sensor (Optional) Motion Sensor
Protection Class
ClassⅠ
Finishing Color(Optional)
Black RAL9017(Standard) / White RAL9016 Optional
Material
Aluminum+Toughened Glass
Lifespan/hrs
62.000 Hrs (Ta=30℃@L70)
Operation Temp/℃
40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃
- 40°C to + 65°C(-40°F to 149°F)
Switching Cycles 100,000 Times
Certificate
CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 4
Character/Power
100W
150W
200W
240W
300W
100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 5
A / mm
389
389
437
493
582
B / mm
297
297
346
379
444
C / mm
57
57
57
57
60

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 6
100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 7
100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 8
100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 9100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 10
100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 11

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 12

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 13

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 14

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 15

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 16
Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-FL050-CGXX
3.6
355*350*165
4.5
1PCS/CTN
DR-FL100-CGXX
3.8
355*350*165
4.7
1PCS/CTN
DR-FL150-CGXX
4.5
415*410*175
5.8
1PCS/CTN
DR-FL200-CGXX
5.7
475*470*195
7.3
1PCS/CTN
DR-FL300-CGXX
9.3
475*470*195
11.5
1PCS/CTN

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 17
100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 18

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 19

100 Watt Modular LED FlooAd Light 3000K to 6500K CCT 5 Years Guarantee For Billboard 20

Dualrays 50W Aluminium Housing LED Flood Light IP66 Waterproof With Adjustable Beam Angle

Q1: What is the warranty for the F4 LED Flood Light?
RE: For the F4 Series LED flood light,Dualrays provide 5 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

Q2: What is colour temperature?
RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
the warmer the light given by the LED:
Warm white = 3000±200K
Natural white = 4000±200K
Pure white = 5000±200K
Cool white = 5700±200K

Q3: Is there a MOQ?
RE: 2PCS

Q4: What is the Lead time?

RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.



Q5: Can you do DIAlux Simulation?
RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

Q6: Do you offer mounting accessories?

RE: Yes, please contact us for details.



Q7: Do you offer OEM or ODM?
RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:
1. We can provide you with our present products with your own label;
2. We can modify our products as your request;
3. We can even develop totally new products based on your design;

Q8: What‘re the chips and drivers used?
RE: High brightness San‘an SMD2835 LEDs light source,flicker free drivers for option.

Q9: What is the CRI?

RE: Ra>80 for standard.



Q10: IP Rating?
RE: IP66.

Q11: Labeling ?
RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

Q12: Finish color?
RE: Standard colors: Silver,other colors can be customized, based on MOQ 50PCS.

Q13: Dimming functions?
RE: PIR sensor,Emergency,1-10V,DALI,Microwave sensor is available.

Q14: Is there cheap shipping cost to import to our country?
RE: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much time.For urgent
orders,we suggest via air to airport plus our ship partner send to your door.

Q15:Can we get support if we have our own market position?
RE: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.
