Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application

  • Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application
  • Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application
  • Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application
Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application
Product Details:
Place of Origin: China
Brand Name: DUALRAYS
Certification: CE,RoHS,TUV/GS,LM79,LM80
Model Number: DR-TPL040-BG41
Payment & Shipping Terms:
Minimum Order Quantity: 8pcs
Price: Negotiable
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 business days
Payment Terms: Western Union, T/T, L/C
Supply Ability: 100000PCS/Month
Contact Now
Detailed Product Description
Rated Power: 40W LEDs Typ/Qty: SMD2835 273pcs
Luminous Flux: 6,400±5% Power Factor: PF>0.9
Lumen Maintenance @ 6000 Hrs: >90% Switching Cycle Before Failure: 100,000
Warranty: 5 Years Power Supply: Boke
Highlight:

led weatherproof batten

,

warm white led batten

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application



Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 0





Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 1


Dualrays D2 Series 40W LED Tri Proof Light--Detailed Product Description

Model No.: DR-TPL040-BG41 Beam Angle: 120°
Power: 40W Protection: IP66,IK10
Lumen Maintenance @ 6000 hrs >90% Power Factor PF>0.9
Warranty: 5 Years Luminous Flux 6,400±5%



Dualrays D2 Series 40W LED Tri Proof Light--Features
> Highly brightness EPISTAR/SAN‘AN SMD2835 LEDs,energy efficient - up to 160 lm/w;
> 1-10V dimming flicker-free driver;
> Single or Double wiring;
> IP66 and IK10 for all industrial areas of application;
> Eco full plastic light design,save your cost and freight;
> No UV or IR and completely mercury free;
> L80/B10 @ 50.000h;
> Sensor control avaliable;
> No toxic heavy metals, VOC, or mercury were used in the design;
> 5 years warranty;

Dualrays D2 Series 40W LED Tri Proof Light--Options:
> Driver: DUALRAYS Own-developed flicker-free driver,BOKE DIP switch power adjustable driver.
> Controls and Dimming: Zigbee wireless control / 1-10V Dimming / Daylight sensor,microwave sensor,CCTadjustable,emergency.
> Plug : European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable optional.
> Suspended/Surface mounted/Adjustable installation for option.
> Single or double wiring and connection.
> Customized supported for special projects.
> Sensor: Daylight Sensor/ Microwave Sensor.

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 2
* Replacement for fluorescent NCF
* Workshops and warehouse
* Garage and car parks
* Sport facility
* Corridor/Gallery/Corridor
* Outdoor & Indoor Locations


Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 3

Model No. DR-TP020-BG2XPX DR-TP030-BG4XPX DR-TP040-BG4XPX DR-TP040-BG5XPX DR-TP050-BG5XPX
System Watts/W 20W 30W 40W 40W
50W
System Efficiency/LPW 120LPW / 140LPW Optioanl
Lumen Output/lm 2.400/2.800±5% 3.600/4.200±5% 4.800/5.600±5% 4.800/5.600±5% 6.000/7.000±5%
Rated Input Voltage/V AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
LEDs Light Source SMD2835
SDCM <6
CCT/K 5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra >80Ra (>70Ra for Option)
Power Factor >0.94
THD <10%
Beam Angle(Optional) 120°
UGR <22
LED Driver DUALRAYS Own Developed High PF Interior Driver
IP Rating IP65
IK Level IK08
Dimming(Optional) 1-10V
Sensor(Optional) No
Emergency(Optional) No
Protection Class ClassⅠ
Finishing Color(Optional) White RAL9016 Optional
Material PC+PC
Lifespan/hrs 50.000 Hrs (Ta=30℃@L70)
Operation Temp/℃ 40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃ - 40°C to + 65°C(-40°F to 149°F)
Installation(Optional) Suspension / Ceiling Mounting Optional
Certificate CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available


Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 4

Character/Length
2ft
4ft
5ft
Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 5
A
600mm
1200mm
1500mm
B
74mm
74mm
74mm
C
74m
74mm
74mm


Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 6

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 7

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 8
Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 9
Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 10

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 11
(I) Emergency Function

Model No.
Emergency Time (Hours)
Emergency Power (W)
Battery Parameters
DR-TPL020-BG21
3/2/1 hours for option
10W
 7.4V/4400/3000/1500mAh Lithium Battery
DR-TPL040-BG41
3/2/1 hours for option
10W
11.1V/6000/4000/2000mAh Lithium Battery
DR-TPL050-BG51
3/2/1 hours for option
10W
 11.1V/8800/6000/3000mAh Lithium Battery



Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 12
Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 13


Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 14
DALI Device
Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 15

DALI Intelligent Control Diagram
Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 16 Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 17

DALI Intelligent Control Operator Interface
Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 18

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 19
Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 20

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 21

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 22

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 23


Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 24

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 25

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 26

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 27

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 28



Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 29



Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 30

Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 31
Dualrays D2 Series 40W Environment Fiendly Led Tri Proof Light with 5 Years Warranty for Workshops Warehouse Application 32
