1000W PFC LED Sports Floodlights High Thermal 140lmW IP66 Meanwell / Sosen Driver

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	DUALRAYS/OEM/ODM/OBM Optional
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-HB200DNN-8XX -BCP-BGBX03
Document:	DUALRAYS LIGHTING Catalogue...26.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Please inquiry for the latest price
Packaging Details:	DUALRAYS/OEM/ODM/OBM Package Optional
Delivery Time:	5-15 business days
Payment Terms:	T/T,L/C,Paypal
Supply Ability:	100,000PCS/Month

Contact Now

Detailed Product Description

Rated Power:	100W DIP(60/80W/100W) 150W DIP(100W/120W/150W) 200W DIP(120W/150W/200W)	LEDs Typ/Qty:	SMD2835
Dimming Control:	ON-OFF \| 1-10V Dimming \| DALI-2 \| Zigbee	IP Rating:	IP66
AC Input Vol:	100~277VAC/ 50/60Hz, 140-280VDC	Power Factor:	PF>0.96
Lumen Maintenance @ 6000 Hrs:	>90%	Power Supply:	SOSEN / Meanwell/PHILIPS Optional
Highlight:	1000W PFC led sports floodlights , led sports floodlights IP66 , Sosen Driver outdoor sports lighting

Dualrays F5 Series 1000W PFC LED Sports Ground Floodlights High Thermal 140lmW IP66

1000W PFC LED Sports Floodlights High Thermal 140lmW IP66 Meanwell / Sosen Driver

> High brightness LUXEON SMD3030 LEDs,energy efficient - up to 150 lm/w;

> Die-casting Al for excellent heat dissipation;

> Superior PC reflector-optic for low glare applications;

> IP66 and IK10 for all industrial areas of application;

> Driver and housing separated by spacers;

> 10°/25°/45°/60°/90°/30*70°/80*140°/60*130°beam angle optional;

> D-Mark tested for the use in paper production, wood processing etc;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> High quality Meanwell/Sosen power supply, AC100V~277V, 50/60Hz input voltage, constant voltage or constant current output, quick responds, no flicker, lightning protection, PFC function available

> CE, RoHS listed, TUV/GS pending, LM79/LM80 available, 5 years guarantee.

LED Sport Ground Floodlight--Data sheet

Item No.	DR-FL1000-EG2	Housing color	Silver, Black, Grey etc
Input Voltage	AC100-277V 50/60HZ	CRI	>80
Power	1000W	IP Ranking	IP66
Working Temp	-40 to +50℃	Power Factor (PF)	＞0.9
Beam Angle	25°/45º/60°/90º	LED Efficiency	150LPW
CCT	2700-6500K	Certificate	CE, RoHS
Dimension	*785395235mm*	Warranty	5 years

Options:

> Driver: ELG/HLG(Retangle),Sosen;

> Controls and Dimming: 1-10V, DALI, PWM,Zigbee Wireless Dimming for option;

> ±90° adjustable European bracket;

> Installation:Ground Mounting, Wall Mounting, Ceiling Mounting,pipe mounting;

> Customized supported for special projects;

> Advertising, Billboard lighting

> Building exterior lighting

> Warehouse, Factory, stair corridors lighting

> Large and small parking, Square, Stadium lighting etc

> Bridges and public places, as well as other industrial and commercial lighting

> Gardens lighting
> Football court,tennis court ect sport lighting area

> Suitable for wet locations
