Dualrays D3Triproof Industry Lighting 20w 30w 40w 50w 150lpw Triproof Light Led Fixture Used For Parking Lot Ce Rohs Saa
> BASELine Version:
> PROLine Version: 120(Milky Cover)~130LPW(Transparent Cover)
> PRIMELine Version: 150(Milky Cover)~160LPW(Transparent Cover)
>High Brightness SAN'AN SMD2835 LEDs,BOKE High PF Flicker-free Driver DIP Switch Power Adjustment Optional;
> Against Water Pressure of 100bar(1450psi) and Temperature of 80°C;
> IP69K PMMA IK06 Anti-ammonia/UV /PC IK10 Anti-UV Protection;
> 120°beam angle;
> Single or Double Wiring Optional,Linkabkle Thorugh Double End Wiring;
> Multiple Installations: Suspension, Wall Mounting;
> Various intelligent control: 1-10V, DALI, Motion sensor,Daylight sensor,
> 304/316 Stainless Steel End Cap & Bracket,corrosion-proof;
> No UV or IR and completely mercury free;
> L70/B20 @ 54.000h;
> Customized supported for special projects;
> SAN'AN SMD2835 LEDs: LM80/TM-21 Available;
> LM79/TM21/ISTMT/LCP and IES/LDT files available;
(D6 LED Triproof Light)
> Europe Market:CE(EMC+LVD),RoHS,TUV/GS,CB Pending,D-Mark;
> North American Market: ETL/CETL,DLC Premium Pending;
> Oceania Market: SAA,C-Tick,RCM
| l No. |
DR-TP020-CG2XPX |
DR-TP030-CG4XPX |
DR-TP040-CG4XPX |
DR-TP040-CG5XPX |
DR-TP050-CG5XPX |
| System Watts/W |
20W |
30W |
40W |
40W |
50W |
| System Efficiency/LPW |
130LPW / 160LPW Optioanl |
| Lumen Output/lm |
2.600/3.200±5% |
3.900/4.800±5% |
5.200/6.400±5% |
5.200/6.400±5% |
6.500/8.000±5% |
| Rated Input Voltage/V |
AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional) |
| LEDs Light Source |
SMD2835 |
| SDCM |
<6 |
| CCT/K |
5000K for Standard (3000K/4000K/5700K/6500K Optional) |
| CRI/Ra |
>80Ra (>70Ra for Option) |
| Power Factor |
>0.91 |
| THD |
<10% |
| Beam Angle(Optional) |
120° |
| UGR |
<22 |
| LED Driver |
BOKE Fixed Power/ DIP Switch Power Adjustable Optional |
| IP Rating |
IP65 |
| IK Level |
IK08 |
| Dimming(Optional) |
1-10V, DALI,Zigbee |
| Sensor(Optional) |
Daylight sensor/Microwave Sensor |
| Emergency(Optional) |
5W@3 Hours or Customized |
| Protection Class |
ClassⅠ |
| Finishing Color(Optional) |
White RAL9016 Optional |
| Material |
PC+PC |
| Lifespan/hrs |
54.000 Hrs (Ta=30℃@L70) |
| Operation Temp/℃ |
40°C to + 50°C(-40°F to 122°F) |
| Storage Temp/℃ |
- 40°C to + 65°C(-40°F to 149°F) |
| Installation(Optional) |
Suspension / Ceiling Mounting Optional |
| Certificate |
CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available |
In addition,we can provide our customers value added service with Dialux software for lighting design projects free of charge.
Dualrays adheres to independent innovation, Dualraysers try to build a world well-known LED industrial Lighting Brand.
