| Place of Origin: | Shenzhen,China |
| Brand Name: | DUALRAYS |
| Certification: | CE,RoHS,LM79,LM80,TUV/GS |
| Model Number: | DR-ULM055-DE5C |
| Minimum Order Quantity: | 8PCS |
|---|---|
| Price: | Negotaited |
| Packaging Details: | Netural Package/OEM and ODM Package Available |
| Delivery Time: | 5-15 Bussiness Day |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50000PCS/Month |
| Watts: | 55W | Lumen: | 9350±5% |
|---|---|---|---|
| Line: | 5 Lines | Finishing Color(Optional): | RAL9016 |
| Dimming: | Non-dimming | LED Chip: | SMD2835 |
| High Light: | 170lmw LED Linear Lamp,SMD2835 LED Linear Lamp,55W LED Linear Fluorescent Tube |
||
55W 170lmw LED linear model non-dimming wide beam angle
| Item | Symbol | Description |
| Model No | / | DR-ULM055-DE5C |
| Length | mm | 1430 |
| Replacement | W | 2.56W |
| LEDs source | / | SMD2835 |
| Driver | / | BOKE Non-dimming LED Driver |
| Optics Cover | / | Wide beam angle |
| AC Input Vol | V | AC220-240V/DC180-264V |
| Output Vol | V | DC32V |
| Warranty | Years | 5 years |
| Operation Temper | ℃ | -40 ~ +55℃ |
Feature
a. Wide, medium, sharp and asymmetric beams for options;
b. BOKE flicker-free driver,with non-dimming,1-10V,DALI dimming, AC/DC input;
c. Much more elegant cable layout, 5 lines, 7 lines and emergency function available;
d. Customized dimming type or emergency function,please contact us for confirmation;
Advantage
* Well work with VEKO, Trilux, Siteco, Thron trunking rails;
* Customized solutions for Mercedes Assembly line in Stuttgart;
* Excellent experience for distributors, wholesales and contractor from Western Europe and Oceania;
* Our service and products are recognized from famous enterprises such as Jalasoft, Mercedes-Benz, Rewe, Nahkauf, Hagebau,etc.
Application
* Office
* Workshops and warehouse
* Supermarkets
* Underground parking
In addition,we can provide our customers value added service with Dialux software for lighting design projects free of charge.
