Name: DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: D5 Series
Availability: InStock

Home Products LED Moisture-proof Lamp

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	D5 Series

Payment & Shipping Terms:

Minimum Order Quantity:	10PCS
Price:	Negotiated
Packaging Details:	Netural Package
Delivery Time:	5-15 business days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Power:	20W/30W/50W/60W/80W	Input Voltage:	AC100-277V
Power Efficiency:	92%	Power Factor:	0.98
CRI:	>83Ra	IP Rating:	IP65
Highlight:	explosion proof led lights , vapor proof led light

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W

Detailed Product Description

Model No.:	D5 Series	CRI:	>83Ra
Power:	20W/30W/50W/60W/80W	AC Input Vol:	AC200~277V 50-60Hz
LEDs Qty:	144/240/336/576PCS	Beam Angle:	120°
Led Light Source:	SMD2835	Warranty:	3 Years

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 0

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 1

Product Material:

* Full plastic housing with high transmittance arcrylic cover,light and economic design concept;
* Luminaire coated in an environmentally friendly polyester powder formulated for a durable and long-lasting color in a silvery,black and
white finish. No toxic heavy metals, VOC, or mercury were used in the design;
* BOKE flicker-free constant current driver is isolated away from the heat source of the LEDs,keeps the stability and performance of the driver for long life,
quick responds,no flicker, lightning protection, PFC function,0-10V,DALI dimming and PIR sensor;
* 100LPW Standard Version,130LPW Proline Version,160LPW Primeline Version for option,CRI>80Ra,more sufficient;

* Train station

* Warehouse

* Supermarkets

* Exhibition center

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 3

Character/Length	2ft	3ft	4ft	5ft
A	600mm	900mm	1200mm	1500mm
B	90mm	90mm	90mm	90mm
C	74mm	74mm	74mm	74mm

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 5

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 6

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 7

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 8

Package:

Size	Power	Outer Carton Size(MM)	G.W(KG)	Qty"/CTN
2ft	20W/30W	655200270	11.3	6PCS
3ft	30W/40W	955200270	16.8	6PCS
4ft	40W/50W/60W	1255200230	15.4	4PCS
5ft	50W/60W/80W	1555200230	17.6	4PCS

Shipment:
DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 10

Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 11

Q1: What is the warranty for the D5 LED triproof light?

RE: For the D5 Series LED triproof light,Dualrays provide 5 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

Q2: What is colour temperature?

RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
the warmer the light given by the LED:

Warm white = 3000±200K

Natural white = 4000±200K

Pure white = 5000±200K

Cool white = 5700±200K

Q3: Is there a MOQ?

RE: 10PCS

Q4: What is the Lead time?

RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.

Q5: Can you do DIAlux Simulation?

RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

Q6: Do you offer mounting accessories?

RE: Yes, please contact us for details.

Q7: Do you offer OEM or ODM?

RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:

1. We can provide you with our present products with your own label;

2. We can modify our products as your request;

3. We can even develop totally new products based on your design;

Q8: What‘re the chips and drivers used?

RE: High brightness San‘an SMD2835 LEDs light source,flicker free drivers for option.

Q9: What is the CRI?

RE: Ra>80 for standard.

Q10: IP Rating?

RE: IP65.

Q11: Labeling ?

RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

Q12: Finish color?

RE: Standard colors: Silver,other colors can be customized, based on MOQ 50PCS.

Q13: Dimming functions?

RE: PIR sensor,Emergency,1-10V,DALI,Microwave sensor is available.

Q14: Is there cheap shipping cost to import to our country?

RE: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much time.For urgent
orders,we suggest via air to airport plus our ship partner send to your door.

Q15:Can we get support if we have our own market position?

RE: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 14

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 15

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 16

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 17

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 18

DUALRAYS D5 Series LED Tri Proof Light IP65 Waterproof Aluminium Alloy Material 20-80W 19

Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
