Name: Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: D2 Series
Availability: InStock

Home Products LED Moisture-proof Lamp

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	D2 Series

Payment & Shipping Terms:

Minimum Order Quantity:	10PCS
Price:	Negotiated
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	5-15 business days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Power:	40W	Length:	4ft
Led Light Source:	SMD2835	Power Factor:	0.98
CRI:	≥83	IP Rating:	IP65
Highlight:	explosion proof led lights , dust proof light fixture

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket

Dualrays D2 Series 40W LED Tri Proof Light-- Detailed Product Description

Model No.:	D2 Series	IP Rating:	IP65
Power:	40W	AC Input Vol:	AC200~277V 50-60Hz
LEDs Qty:	273PCS	CCT/K:	3000/4000/5000/5700K
Led Light Source:	SMD2835	Warranty:	5 Years

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 0

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 1

Dualrays D2 Series 40W LED Tri Proof Light-- Feature

1. Adopting SMD2835 LEDs light source, high output lighting efficiency 120LPW, high Color Rendering Index (CRI>83Ra), excellent heat dissipation, low light decay;

2. 100LPW Standard Version,120LPW Proline Version,160LPW Primeline Version for option, CRI>83 Ra ,more sufficient;

3. 3 years warranty

4. PFC function,0-10V,DALI dimming and PIR sensor are available;

5. Water-proof; Dust-proof; Damp-proof; Vapor-proof

6. BOKE flicker-free constant current driver is isolated away from the heat source of the LEDs,keeps the stability and performance of the driver for long life,quick responds,no flicker, lightning protection, PFC function,0-10V,DALI dimming and PIR sensor;

Dualrays D2 Series 40W LED Tri Proof Light-- Options

> Driver: DUALRAYS Own-developed flicker-free driver,BOKE DIP switch power adjustable driver.

> Controls and Dimming: Zigbee wireless control / 1-10V Dimming / Daylight sensor,microwave sensor,CCTadjustable,emergency.

> Plug : European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable optional.

> Installation: Suspension, Ceilign Mounted and adjustable surface mount.
> Single or double wiring and connection.

> Customized supported for special projects.

1. Train Station
2. Bus Station
3. Supermarket
4. Airport hall

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 3

Model No.	DR-TP020-BG2XPX	DR-TP030-BG4XPX	DR-TP040-BG4XPX	DR-TP040-BG5XPX	DR-TP050-BG5XPX
System Watts/W	20W	30W	40W	40W	50W
System Efficiency/LPW	120LPW / 140LPW Optioanl
Lumen Output/lm	2.400/2.800±5%	3.600/4.200±5%	4.800/5.600±5%	4.800/5.600±5%	6.000/7.000±5%
Rated Input Voltage/V	AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
LEDs Light Source	SMD2835
SDCM	<6
CCT/K	5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra	>80Ra (>70Ra for Option)
Power Factor	>0.94
THD	<10%
Beam Angle(Optional)	120°
UGR	<22
LED Driver	DUALRAYS Own Developed High PF Interior Driver
IP Rating	IP65
IK Level	IK08
Dimming(Optional)	1-10V
Sensor(Optional)	No
Emergency(Optional)	No
Protection Class	ClassⅠ
Finishing Color(Optional)	White RAL9016 Optional
Material	PC+PC
Lifespan/hrs	50.000 Hrs (Ta=30℃@L70)
Operation Temp/℃	40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃	- 40°C to + 65°C(-40°F to 149°F)
Installation(Optional)	Suspension / Ceiling Mounting Optional
Certificate	CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 4

Character/Length	2ft	4ft	5ft
A	600mm	1200mm	1500mm
B	74mm	74mm	74mm
C	74m	74mm	74mm

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 6

(I) Emergency Function

Model No.	Emergency Time (Hours)	Emergency Power (W)	Battery Parameters
DR-TPL020-BG21	3/2/1 hours for option	10W	7.4V/4400/3000/1500mAh Lithium Battery
DR-TPL040-BG41	3/2/1 hours for option	10W	11.1V/6000/4000/2000mAh Lithium Battery
DR-TPL050-BG51	3/2/1 hours for option	10W	11.1V/8800/6000/3000mAh Lithium Battery

1. Interior circuit with emergency device has been already connected;

2 4 wire output.(EuMarket:Blue-Neutralwire/Black-Livewire/Brown-Switchwire/Yellow&Green-Earthwire)

3 Indicator color(Green–main power, Yellow–malfunction,Red-Charging)

4 Battery can be recharged at least 500 times.In order to maintain the battery,it must be discharged every 3 months.
Remark: MSDS Test Report is available.

(II) 0-10V Dimming

(II) Microwave Sensor 2 Stage Dimming Type

a. With 5.8G Hz microwave technology, stable detection performance and long life time.

b. Detection zone Max. is 16m*8m (D*H) MC003V/D.

Stand-by dimming level in 10% / 20% / 30% / 40% / 50%.

Stand-by period has 5s / 5min / 10min / 30min / 1h / Disable.

c. Water proof sensor with IP65 rating.

d. Built-in adjustable daylight sensor.

e. 2 step dimming function 100% ---> low light (Never turn off)

f. 3 step dimming function

100% ---> low light(10%,20%,30%,40%,50%) ---> off

g. Automatic dimming when used in combination with 1-10V dimmable control gears.

Packaging Information

Size	Net Weight/PCS	Outer Carton Size	G.W	Quantity/CTN
2ft	0.9kg	L670xW440xH200mm	13.2kg	10PCS
4ft	1.8kg	L1270xW360xH200mm	17.5kg	8PCS
5ft	2.1kg	L1570xW360xH200mm	20.6kg	8PCS

Shipment
Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 11

Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 12

Q1: What is the warranty for the D2 LED triproof light?

RE: For the D2 Series LED triproof light,Dualrays provide 3 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

Q2: What is colour temperature?

RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
the warmer the light given by the LED:

Warm white = 3000±200K

Natural white = 4000±200K

Pure white = 5000±200K

Cool white = 5700±200K

Q3: Is there a MOQ?

RE: 10PCS

Q4: What is the Lead time?

RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.

Q5: Can you do DIAlux Simulation?

RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

Q6: Do you offer mounting accessories?

RE: Yes, please contact us for details.

Q7: Do you offer OEM or ODM?

RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:

1. We can provide you with our present products with your own label;

2. We can modify our products as your request;

3. We can even develop totally new products based on your design;

Q8: What‘re the chips and drivers used?

RE: High brightness San‘an SMD2835 LEDs light source,flicker free drivers for option.

Q9: What is the CRI?

RE: Ra>80 for standard.

Q10: IP Rating?

RE: IP65.

Q11: Labeling ?

RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

Q12: Finish color?

RE: Standard colors: Silver,other colors can be customized, based on MOQ 50PCS.

Q13: Dimming functions?

RE: PIR sensor,Emergency,1-10V,DALI,Microwave sensor is available.

Q14: Is there cheap shipping cost to import to our country?

RE: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much time.For urgent
orders,we suggest via air to airport plus our ship partner send to your door.

Q15:Can we get support if we have our own market position?

RE: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 15

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 16

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 17

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 18

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 19

Dualrays D2 Series 40W LED Tri Proof Light IP65 Vapor Proof IK10 With Boker Driver For Supermarket 20

Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
