Name: Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: DR-TPL040-BG41
Availability: InStock

Home Products LED Moisture-proof Lamp

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-TPL040-BG41

Payment & Shipping Terms:

Minimum Order Quantity:	10PCS
Price:	Negotiated
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	5-15 business days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Power:	40W	Length:	4ft
Power Efficiency:	92%	Power Factor:	0.98
Guarantee:	5 Years	Drive:	Boke
Highlight:	explosion proof led lights , vapor proof led light

Dualrays D5 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 0

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 1

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 2

Dualrays D5 Series 40W LED Tri Proof Light -- Detailed Product Description

Model No.:	DR-TPL040-BG41	Color Index:	>80Ra
Power:	40W	AC Input Vol:	AC200~277V 50-60Hz
LEDs Qty:	273PCS	Length:	4ft
Life Span:	50,000hrs	Warranty:	5 Years

Dualrays D5 Series 40W LED Tri Proof Light-- Features

1.Full plastic housing with high transmittance arcrylic cover,light and economic design concept;

2. Luminaire coated in an environmentally friendly polyester powder formulated for a durable and long-lasting color in a silvery,black and
white finish;

3.100LPW Standard Version,130LPW Proline Version,160LPW Primeline Version for option,CRI>80Ra,more sufficient;

4. PFC function,0-10V,DALI dimming and PIR sensor

5. BOKE flicker-free constant current driver is isolated away from the heat source of the LEDs,keeps the stability and performance of the driver for long life,quick responds,no flicker, lightning protection, PFC function,0-10V,DALI dimming and PIR sensor;

1. Supermarkets
2. Exhibition center
3. Warehouse
4. Airport hall

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 4

Model No.	DR-TP020-BG2XPX	DR-TP030-BG4XPX	DR-TP040-BG4XPX	DR-TP040-BG5XPX	DR-TP050-BG5XPX
System Watts/W	20W	30W	40W	40W	50W
System Efficiency/LPW	120LPW / 140LPW Optioanl
Lumen Output/lm	2.400/2.800±5%	3.600/4.200±5%	4.800/5.600±5%	4.800/5.600±5%	6.000/7.000±5%
Rated Input Voltage/V	AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
LEDs Light Source	SMD2835
SDCM	<6
CCT/K	5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra	>80Ra (>70Ra for Option)
Power Factor	>0.94
THD	<10%
Beam Angle(Optional)	120°
UGR	<22
LED Driver	DUALRAYS Own Developed High PF Interior Driver
IP Rating	IP65
IK Level	IK08
Dimming(Optional)	1-10V
Sensor(Optional)	No
Emergency(Optional)	No
Protection Class	ClassⅠ
Finishing Color(Optional)	White RAL9016 Optional
Material	PC+PC
Lifespan/hrs	50.000 Hrs (Ta=30℃@L70)
Operation Temp/℃	40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃	- 40°C to + 65°C(-40°F to 149°F)
Installation(Optional)	Suspension / Ceiling Mounting Optional
Certificate	CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 5

Character/Length	2ft	4ft	5ft
A	600mm	1200mm	1500mm
B	74mm	74mm	74mm
C	74m	74mm	74mm

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 7

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 9

DALI Device
Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 12

DALI Intelligent Control Diagram

DALI Intelligent Control Operator Interface

Packaging Information

Size	Net Weight/PCS	Outer Carton Size	G.W	Quantity/CTN
2ft	0.9kg	L670xW440xH200mm	13.2kg	10PCS
4ft	1.8kg	L1270xW360xH200mm	17.5kg	8PCS
5ft	2.1kg	L1570xW360xH200mm	20.6kg	8PCS

Shipment
Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 24

Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 25

Q1: What is the warranty for the D2 LED triproof light?

RE: For the D2 Series LED triproof light,Dualrays provide 3 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

Q2: What is colour temperature?

RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
the warmer the light given by the LED:

Warm white = 3000±200K

Natural white = 4000±200K

Pure white = 5000±200K

Cool white = 5700±200K

Q3: Is there a MOQ?

RE: 10PCS

Q4: What is the Lead time?

RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.

Q5: Can you do DIAlux Simulation?

RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

Q6: Do you offer mounting accessories?

RE: Yes, please contact us for details.

Q7: Do you offer OEM or ODM?

RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:

1. We can provide you with our present products with your own label;

2. We can modify our products as your request;

3. We can even develop totally new products based on your design;

Q8:Can we get support if we have our own market position?

RE: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.

Q9: What is the CRI?

RE: Ra>80 for standard.

Q10: IP Rating?

RE: IP65.

Q11: Labeling ?

RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

Q12: Finish color?

RE: Standard colors: Silver,other colors can be customized, based on MOQ 50PCS.

Q13: Dimming functions?

RE: PIR sensor,Emergency,1-10V,DALI,Microwave sensor is available.

Q14: Is there cheap shipping cost to import to our country?

RE: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much time.For urgent
orders,we suggest via air to airport plus our ship partner send to your door.

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 28

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 29

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 30

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 31

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 32

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 33

Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!

Dualrays D2 Series 40W Suspending Mounted LED Tri Proof Light 4ft Boker Driver Energy Saving For Poultry Farm 35

Marketing Department

Tel: 0086-755-2306 6948

Fax: 0086-755-6164 1072

Zip Code: 518125

Contact person: Cila Zhang
Email: sales08@dualrays.com
Add: 6th Floor,Building 10, Gangzai Industrial Park, Furong Industrial Park,Xinqiao Industrial District,Shajing,Bao‘an District,Shenzhen 518125, P.R.China
