50W 1500mm PC LED Batten Tri proof Light Mist Proof Light Fixtures

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-TP020-BHG2XPX

Payment & Shipping Terms:

Minimum Order Quantity:	8pcs
Packaging Details:	Netural Package,color box package,8PCS/CTN,L1270*W360xH200mm
Delivery Time:	5-15 business days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Material:	Aluminium Alloy	Installation:	Suspending/Ceilling
Length:	5ft	IP Rating:	IP66
CCT:	3000k~5700K	Guarantee:	5 Years
High Light:	explosion proof led lights , vapor proof led light

50W 1500mm PC LED Batten Tri-proof Light Mist Proof Light Fixtures

> Highly brightness EPISTAR/SAN‘AN SMD2835 LEDs,energy efficient - up to 160 lm/w;

> 2 in 1 design concept,integrated PC cover and PCBA,seperated housing,convenient installation,labor cost saving;

> Multiple Link with double wiring;

> L80/B10> 50.000h;

> Hi-slim design,elegent and fashional;

> Buckle Design End-cap,pretty Easy for Wiring and Installation;

> High Brightness SAN‘AN SMD2835 LEDs, DUALRAYS Own Developed High PF Flicker-free Driver;

> Full Plastic Material,Eco and Environment Friendly;

> IP65 / IK08 Protection;

> 120°beam angle;

> Linkabkle Through Double End Wiring;

> Multiple Installations: Suspension, Wall Mounting

> No UV or IR and completely mercury free;

> L70/B20 @ 52.000h;

> Customized supported for special projects;

Options:

> Plug: European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable;

> Installation : Suspension, Wall Mounting;

> Replacement for fluorescent NCF;

> Workshops and warehouse;

> Garage and car parks;

> Sport facility;

> Corridor/Gallery/Corridor;

> Outdoor & Indoor Locations;

Model No.	DR-TP020-BHG2XPX	DR-TP030-BHG2XPX	DR-TP040-BHG2XPX	DR-TP040-BHG2XPX	DR-TP050-BHG2XPX
System Watts/W	20W	30W	40W	40W	50W
System Efficiency/LPW	120LPW / 140LPW Optioanl
Lumen Output/lm	2.400/2.800±5%	3.600/4.200±5%	4.800/5.600±5%	4.800/5.600±5%	6.000/7.000±5%
Rated Input Voltage/V	AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
LEDs Light Source	SMD2835
SDCM	<6
CCT/K	5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra	>80Ra (>70Ra for Option)
Power Factor	>0.91
THD	<10%
Beam Angle(Optional)	120°
UGR	<22
LED Driver	DUALRAYS Own Developed High PF Interior Driver
IP Rating	IP65
IK Level	IK08
Dimming(Optional)	1-10V
Sensor(Optional)	No
Emergency(Optional)	No
Protection Class	ClassⅠ
Finishing Color(Optional)	White RAL9016 Optional
Material	PC+PC
Lifespan/hrs	52.000 Hrs (Ta=30℃@L70)
Operation Temp/℃	40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃	- 40°C to + 65°C(-40°F to 149°F)
Installation(Optional)	Suspension / Ceiling Mounting Optional
Certificate	CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available
