Name: Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: DR-TP040-AG41
Availability: InStock

Home Products LED Moisture-proof Lamp

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-TP040-AG41

Payment & Shipping Terms:

Minimum Order Quantity:	8pcs
Packaging Details:	Netural Package,color box package,8PCS/CTN,L1270*W360xH200mm
Delivery Time:	5-15 business days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Material:	PC	Input Voltage:	AC200-240V
Power Efficiency:	92%	Power Factor:	0.95
CRI:	>80	CCT:	3000k~6000K
IP Rating:	IP66	Guarantee:	5 Years
Highlight:	dust proof light fixture , vapor proof led light

LED Batten Tri-proof Light 1200mm 40W 5000K Full Plastic Housing

> Highly brightness EPISTAR/SAN‘AN SMD2835 LEDs,energy efficient - up to 160 lm/w;

> 1-10V dimming flicker-free driver,DIP Switch Power Adjustment available,CCT adjustable available;

> Single or Double wiring,backside cable output avaialable;

> IP65 and IK08 for all industrial areas of application;

> 2 in 1 design concept,integrated PC cover and PCBA,seperated housing,convenient installation,labor cost saving;

> Multiple Link with double wiring;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> 5 years warranty;

Options:

> Driver: DUALRAYS Own-developed flicker-free driver,BOKE DIP switch power adjustable driver.

> Controls and Dimming: Zigbee wireless control / 1-10V Dimming / Daylight sensor,microwave sensor,CCTadjustable,emergency.

> Plug : European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable optional.

> Installation: Suspension.
> Single or double wiring and connection.

> Customized supported for special projects.

* Replacement for fluorescent NCF

* Workshops and warehouse

* Garage and car parks

* Sport facility

* Corridor/Gallery/Corridor

* Outdoor & Indoor Locations

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 2

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 3

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 4

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 8

DALI Device

DALI Intelligent Control Diagram

DALI Intelligent Control Operator Interface

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 17
Packaging Information

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 19

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 20

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 21

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 22

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 23

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 24

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 25

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 26

Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 27

In addition,we can provide our customers value added service with Dialux software for lighting design projects free of charge.
Led Batten Tri Proof Light 1200mm 40W 5000K Full Plastic Housing 28

(DIALUX Simulation)

　　Dualrays adheres to independent innovation, Dualraysers try to build a world well-known LED industrial Lighting Brand.　　
