Name: 160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa
Brand: DUALRAYS
SKU: DR-HB240-DG2
Price: 1.00 USD
Availability: InStock
Rating: 4.9 (183 reviews)

Home Products UFO LED High Bay Light

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-HB240-DG2

Payment & Shipping Terms:

Minimum Order Quantity:	10PCS
Price:	Negotiated After Inquiry
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	5-15 Bussiness Day
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50000PCS/Month

Contact Now

Detailed Product Description

System Watts/W:	100W/150W/200W/240W	System Efficiency/LPW:	140LPW
Rated Input Voltage/V:	AC100~277V 50/60Hz	LEDs Light Source:	SMD3030
CCT:	3000/4000/5700/6500K±200K	CRI:	>83Ra
Beam Angle(Optional):	60°/90°/110°	Surge Protection:	6~10KV SPD Driver,Exterior SPD 10KV() Or 20KV Meanwell Optional
High Light:	led flat panel light fixture , wireless led outdoor flood lights

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installation

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 1

> Factories / Warehouses / Supermarket

> Exhibitions / Showrooms / Animal Farm

> Barns and Riding Halls / Logistic Center

> High Rooms and Halls / Stadium / Chemical Plant

> Traditional lamp replacement

Model No.	DR-HB100-DGXP	DR-HB150-DGXP	DR-HB200-DGXP	DR-HB240-DGXP
System Watts/W	100W	150W	200W	240W
System Efficiency/LPW	140LPW / 160LPW Optional
Lumen Output/lm	14.000 / 16.000±5%	21.000 / 24.000±5%	28.000 / 32.000±5%	33.600 / 38.400±5%
Rated Input Voltage/V	AC100~277V, 50/60Hz
LEDs Light Source	SMD2835
SDCM	<5
CCT/K	5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra	>70Ra (>80Ra for Option)
Power Factor	>0.95
THD	<10%
Beam Angle(Optional)	60°/90°/120°
UGR	<25
Surge Protection	3.75~4KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver	DUALRAYS Own-developed High Efficiency Non-isolated Driver
IP Rating	IP65
Dimming(Optional)	0/1-10V/DALI/Zigbee
Sensor(Optional)	Motion Sensor,Daylight Sensor
Emergency(Optional)	Available (30W @ 3Hrs for Standard)
Protection Class	ClassⅠ
Finishing Color(Optional)	Black RAL9017(Standard) / White RAL9016 Optional
Material	Aluminum+PC
Lifespan/hrs	70.000 Hrs (Ta=30℃@L70)
Operation Temp/℃	40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃	- 40°C to + 65°C(-40°F to 149°F)
Installation(Optional)	Loop Hanging, Ceiling Mounting, Wall Mounting
Certificate	CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 4

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 14

Model No.	DR-HB100-DGXP	DR-HB150-DGXP	DR-HB200-DGXP	DR-HB240-DGXP
System Watts/W	100W	150W	200W	240W
System Efficiency/LPW	140LPW
Lumen Output/lm	14.000±5%	21.000±5%	28.000±5%	33.600±5%
Finishing Color(Optional)	Black RAL9017 / White RAL9016
Protection Class	ClassⅠ
LED Driver	Meanwell HBG/ELG/HLG,Sosen
Surge Protection	6~10KV SPD Driver,Exterior SPD 10KV() or 20KV Meanwell Optional
Rated Input Voltage/V	AC100~277V 50/60Hz
LEDs Light Source	SMD3030
SDCM	<6
CCT/K	3000K/4000K/5000K/5700K/6500K

> Highly brightness LUXEON SMD3030 LEDs,energy efficient - up to 160 lm/w;

> Die-casting Al for excellent heat dissipation;
> Pluggable built-in radar motion sensor,plug and play;

> Superior PC reflector-optic for low glare applications,PMMA,glass cover available;

> IP65 and IK10 for all industrial areas of application;

> Driver and housing separated by spacers;

> Adjustable ripple-lens optic with 60°/90°/120° beam angle;

> D-Mark tested for the use in paper production, wood processing etc;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> 5 years warranty;

Options:

> Driver: Meanwell HBG(Round),ELG/HLG(Retangle),Sosen

> Controls and Dimming: Zigbee wireless control / 1-10V Dimming / Motion sensor / Emergency / DALI control / Daylight sensor.

> Reflector : PC reflector with / without cover.pipe mounting.

> Installation: loop hanging, ceiling mounting, wall mounting,

> Customized supported for special projects.

> Factories / Warehouses /Workshops

> Exhibitions & showrooms

> Barns and riding halls

> High rooms and halls

> Traditional lamp replacement

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 18

Character/Power	100W	150W	200W	240W
A	Ø320mm	Ø320mm	Ø390mm	Ø390mm
B	200mm	200mm	205mm	205mm

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 20

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 22

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 23

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 24

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 25

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 26

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 27

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 28

160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 29
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
160LPW LED High Bay Lighting HB4 Pluggable Motion Sensor Loop Hanging Ceiling Mounting Wall Mount Pipe Mounting Installa 30

Marketing Department

Tel: 0086-755-2306 6948

Fax: 0086-755-6164 1072

Zip Code: 518125

Contact Person: Richard Leo

Whatsapp/Wechat: 0086-157.1083.3783
Email: sales06@dualrays.com
Add: 6th Floor,Building 10, Gangzai Industrial Park, Furong Industrial Park,Xinqiao Industrial District,Shajing,Bao‘an District,Shenzhen 518125, P.R.China

Tag words: Driverless LED flood light , UFO LED high bay , LED troffer , LED area light , LED street light, Dualrays,LED Lichtband System,Linear LED High Bay,Linear LED Low Bay Light,Sport LED Flood Light,LED High Mast Light
