SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle

SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle

  • SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle
  • SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle
  • SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle
  • SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle
Product Details:
Place of Origin: Shenzhen,China
Brand Name: Dualrays
Certification: CE,ROHS,TUV/GS,LM79,LM80
Model Number: DR-SL150-DG2
Payment & Shipping Terms:
Minimum Order Quantity: 2PCS
Price: Negotiated
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 business days
Payment Terms: T/T, L/C, Western Union,Paypal
Supply Ability: 50,000pcs/month
Contact Now
Detailed Product Description
Warranty: 5 Years Efficienncy: 150LPW
LEDs Source: LUMILEDS LUXEON LEDs Driver: Meanwell ELG/HLG
CCT: WW:3000±200K NW: 4000±200K DW:5000±200K CW: 5700±200K Input Voltage: AC95~277V 50/60Hz
Wattage: 30W,60W,90W,120W,150W,180W Life Span: 50000H
High Light:

led cobra head street light

,

decorative street light

SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle





Outdoor LED Street Lights Features:

* Air-flow through heat sink design provides perfect heat management, lighter but stronger construction.

* Top brand conponents,PHILIP LUMILEDS LUXEON LEDs light source,Meanwell ELG/HLG driver,durable;

* Tool-less access to the down-opening driver door makes easy maintenance and 10KV/20KV SPD for option;

* Driver and housing separated by spacers;

* 5 years warranty,7 or 10 years warranty negotiated;

* Zigbee module (Single-lamp Controller and centralized manager) with software for option.



Item Description
LEDs Light Source SMD5050
LED Driver Meanwell ELG/HLG,Sosen
Dimming(Optional) 0/1-10V/PWM/DALI/Zigbee
Rated Input Voltage/V AC100~277V 50/60Hz
Surge Protection 6~10KV SPD Driver,Exterior SPD 10KV() or 20KV Meanwell Optional
Beam Angle(Optional) TypeⅠ/TypeⅡ(Long & Medium)/TypeⅢ(Medium)/TypeⅣ /TypeⅤ (Medium) (Medium)
Power Factor >0.95
CRI/Ra >70Ra (>80Ra for Option)



Support items for the exclusive agent as follows:

(1) According to the commercial plan, Dualrays will grant 3% of the sole agent‘s yearly sales amount to the sole agent for advertising subsidy, which includes trading fairs, television media, newspaper, magazines, website ads and so on. As long as the sole agent could show us the evidence of these advertising actions, such as pictures taken on the trading fair, copies of magazines, website links, etc., the subsidy will be granted every half year. On 1st July, The first half year‘s subsidy will be fulfilled. And the second half of the subsidy only will be fulfilled by 31st December, on the condition that the agent achieved the yearly sales task or above.

(2) As to the world famous trading fairs, Dualrays will offer samples and pay the booth. And the exclusive agent has to cooperate with us to offer our staffs local transportation and accommodations. The customers‘ inquiry from the exclusive market area will belong to the agent, and customer inquiry from other areas will belong to the Dualrays.

(3) Dualrays‘ website and catalogue will post our exclusive agent‘s related information.

(4) The price list for the exclusive agent will be among the lowest in that area, and details will be revealed in the contract. And the exclusive agent could offer constructive suggestions on price defining. The inquiries you got from your local area will be dealt with directly, while Dualrays will deal with the mass order inquiries (above 150000USD) directly. And we will keep the agent informed, and assure to grant the agent 2% commission after the order placed in our company.

(5) Free training and technology support.



SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 0

SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 1
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 2

> Roadways.

> Avenues.

> Walkways.

> Loading Area.

> Parking lot.

> Playground.

> Sport and Stadium.

SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 3
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 4


SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 5
30W/60W Version
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 6
90W,120W/150W/180W Version
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 7

SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 8

SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 9

SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 10
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 11
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 12SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 13SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 14SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 15
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 16
Zigbee Wireless Intelligent Control Diagram
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 17

Zigbee Wireless Intelligent Control Operator Interface
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 18
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 19

SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 20
SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 21

SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 22

SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 23

DUALRAYS Europe Stocking UFO High Bay Lamp Shipment Directly to Netherlands Fast and Local After Sales Service


SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 25

Q1: Is there a MOQ?

RE: No MOQ, Sample order for testing is welcome.

Q2: What is the Lead time?

RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.

Q3: Can you do DIAlux Simulation?

RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

Q4: Do you offer mounting accessories?

RE: Yes, please contact us for details.



Q5. What brands of driver do you supply for luminaire fixture?

RE: Meanwell, Boke, Sosen, Moso and other brands available.



Q6. What brands of LEDs source you supply for your luminaire fixture?

RE: , Osram, Cree, Nichia,etc.



SMD5050 Decorative Street Lamps Intelligent Dimming Control Housing Multi Beam Angle 26
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
