Name: 100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: F4 Series
Availability: InStock

Home Products LED Moisture-proof Lamp

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	F4 Series

Payment & Shipping Terms:

Minimum Order Quantity:	2PCS
Price:	Negotiated
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	5-15 Bussiness Day
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50000PCS/Month

Contact Now

Detailed Product Description

Power Effciency:	92%	CRI:	>83Ra
Warranty:	5 Years	LED's Brand:	LUMILEDS
Input Voltage:	AC100V-277V	LED Light Source:	SMD3030 / 5050 Optional
Beam Angle(Optional):	20°/40°/60°/90°/140*60° Optional	CCT/K:	5000K For Standard (3000K/4000K/5700K/6500K Optional)
LED Driver:	Meanwell ELG / HLG Optional	Operation Temp/℃:	-40°C To + 50°C(-40°F To 122°F)
IP Rating:	IP66
Highlight:	outdoor led flood lights , led yard flood lights

F4 Series 100W UGR<25 Modular LED Flood Light 140 LPW Efficiency LED High Mast Light

Detailed Product Description

Input Voltage:	AC100V-277V	Power Effciency:	92%
Power:	100W	LED's Brand:	LUMILEDS
IP Rating:	IP66	Life Span:	50,000Hrs
LEDs Typ:	SMD3030	Warranty:	5 Years

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 0

* Cross-ventilated back cover for excellent heat dissipation;

* Full Al housing design,>50% efficiency higher than the general flood light in the market;

* High quality Meanwell/Sosen power supply, AC100V~277V,50/60Hz input voltage,constant voltage or constant current output;

* Pure copper air breather,good balance of air pressure inside and outside,water mist cleared at the same time,sustainable and durable;

* Anti-corrosion powder treatment,high anti-corrosion grade WF2, can be used indoor and outdoor prevent corrosion environment;

* Cross-ventilated back cover for excellent heat dissipation;
* 270°～360° adjustable supporting European bracket for actual lighting direction;

* CE,RoHS listed,LM79/LM80 available,5 years guarantee;

* Building exterior lighting

* Stair corridors lighting

* Public places

* Bridges

* Gardens lighting

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 3

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 5

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 6

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 9

Packaging Information:

Model No.	Power	Outer Carton Size(MM)	G.W(KG)	Quantity/CTN
DR-FL050-DGXP	50W	340110190	2.8	1PCS
DR-FL100-DGXP	100W	340110250	4.3	1PCS
DR-FL150-DGXP	150W	340110330	5.2	1PCS
DR-FL200-DGXP	200W	340120400	6.7	1PCS
DR-FL250-DGXP	250W	340120480	7.8	1PCS
DR-FL300-DGXP	300W	340120560	9.2	1PCS
DR-FL400-DGXP	400W	600140400	12.6	1PCS
DR-FL500-DGXP	500W	600140480	13.7	1PCS
DR-FL600-DGXP	600W	600140550	15.7	1PCS

Shipment:

Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 11

Q1: What is the warranty for the F4 LED Flood Light?

RE: For the F4 Series LED flood light,Dualrays provide 5 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

Q2: What is colour temperature?

RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
the warmer the light given by the LED:

Warm white = 3000±200K

Natural white = 4000±200K

Pure white = 5000±200K

Cool white = 5700±200K

Q3: Is there a MOQ?

RE: 2PCS

Q4: What is the Lead time?

RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.

Q5: Can you do DIAlux Simulation?

RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

Q6: Do you offer mounting accessories?

RE: Yes, please contact us for details.

Q7: Do you offer OEM or ODM?

RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:

1. We can provide you with our present products with your own label;

2. We can modify our products as your request;

3. We can even develop totally new products based on your design;

Q8: What‘re the chips and drivers used?

RE: High brightness San‘an SMD2835 LEDs light source,flicker free drivers for option.

Q9: What is the CRI?

RE: Ra>80 for standard.

Q10: IP Rating?

RE: IP66.

Q11: Labeling ?

RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

Q12: Finish color?

RE: Standard colors: Silver,other colors can be customized, based on MOQ 50PCS.

Q13: Dimming functions?

RE: PIR sensor,Emergency,1-10V,DALI,Microwave sensor is available.

Q14: Is there cheap shipping cost to import to our country?

RE: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much time.For urgent
orders,we suggest via air to airport plus our ship partner send to your door.

Q15:Can we get support if we have our own market position?

RE: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 14

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 15

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 16

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 17

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 18

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 19

Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!

100W UGR<25 F4 Series Modular LED Flood Light 140 LPW Efficiency LED High Mast Light 21

Marketing Department

Tel: 0086-755-2306 6948

Fax: 0086-755-6164 1072

Zip Code: 518125

Cila Zhang

wechat/whatsapp:+86-15070843668
Email: sales08@dualrays.com
Add: 3rd Floor,Building A3 | Tianrui Industrial Park | #35,Fuyuan 1st Road,Fuyong Town,Bao'an Dist | Shenzhen 518103
