Name: 140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: DR-ST180-DGXP
Availability: InStock

Home Products LED Street Light

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller

Product Details:

Place of Origin:	Shenzhen, China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80
Model Number:	DR-ST180-DGXP

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Please contact us for details
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	Normally 3-5 business days for samples, 10-15 business days for bulk orders.
Payment Terms:	Western Union, L/C, T/T,Paypal
Supply Ability:	50000PCS/Month

Contact Now

Detailed Product Description

Input Voltage:	AC95~277V 50/60Hz	Driver:	Meanwell/Sosen
LEDs:	LUXEON SMD 3030	Lens:	Type I, Type II, Type III, Type IV, Type V
Power:	30W/60W/90W/120W/150W/180W	Efficiency:	140LPW
Material:	Aluminium Alloy 6063+PC	Beam Angle:	70°x150°/50°x120°
Working Temperature:	-40℃--50℃	Intelligent Control:	10KV/20KV SPD/1-10V, DALI, PWM,Zigbee Wireless Dimming
Highlight:	warm white led street lights , decorative street light

Dualrays S4 Series Intelligent LED Street Light 140LPW efficiency IP66 5 years guarantee
140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 0

> Reliable brand of driver and LEDs, keep stable working and long life of the luminaire;

> Strong Al housing, fluent streamline outlook design, provide good heat dissipation;

> Superior PC reflector-optic for low glare applications,and toughened glass protection;

> IP66 and IK10 for road lighting application;

> Professional 50(V)*120(H)°/75(V)*150°(H) optic for option;

> ±10°/-90°(<90W) or ±15°/-90°(>90W) lamp head adjustable;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> Normally 5 years warranty,7 or 10 years warranty negotiated;

Options:

> Driver and LEDs, to meet your requirements and lower the budget;

> Smart control and surge protector device available;

> Light pole adapter for different poles optional;

> Customized support for special projects;

What values can we bring you?

* Tens of R&D engineers with more than 10 years professional experience in LED luminaries industry, fast, resonponsible and reliable;

* Powerful production capacity and QC management system;

* Provide DIALux software for lighting design project for our customers;

* Have branch office and warehouse in Netherlands with more than 4000㎡. 3 days delivery time, fast reaction.

* Excellent experience for distributors, wholesales and contractor from Western Europe and Oceania;

* Our service and products are recognized from famous enterprises such as Jalasoft, Mercedes-Benz, Rewe, Nahkauf, Hagebau,etc.

* All our LED luminaries comply with CE, RoHS standard. TUV, ENEC, VDE, SAA,C-Tick, LM79,LM80 listed for the leading products;

* Roadways.

* Avenues.

* Walkways.

* Loading Area.

* Parking lot.

* Playground.
* Sport and Stadium.

30W/60W Version
140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 4

90W,120W/150W/180W Version

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 6

Zigbee Wireless Intelligent Control Diagram

Zigbee Wireless Intelligent Control Operator Interface
140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 16

DALI Device
140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 18

DALI Intelligent Control Diagram

DALI Intelligent Control Operator Interface

Packaging Information
140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 23

Shipment
140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 24

Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 25

Q1: What is the warranty?

RE: 5 years warranty. We take responsibility of any quality problem occurred in this period.

Q2: What is colour temperature?

RE: Warm white = 3000±200K

Natural white = 4000±200K

Pure white = 5000±200K

Cool white = 5700±200K

Q3: Is there a MOQ?

RE: 1pcs sample order for testing welcomed, we will make every effort to support you.

Q4: What is the Lead time?

RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.

Q5: Can you do DIAlux Simulation?

RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

Q6: Do you offer mounting accessories?

RE: Yes, please contact us for details.

Q7: Do you offer OEM or ODM?

RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:

1. We can provide you with our present products with your own label;

2. We can modify our products as your request;

3. We can even develop totally new products based on your design;

Q8: What‘re the chips and drivers used?

RE: High brightness NICHIA LEDs light source,Meanwell drivers for standard configuration.

Q9: What Optics available?

RE: LED Street Light: Type I, Type II, Type III, Type IV, Type V for option.

Q10: What is the CRI?

RE: Ra>70, Ra>80 optional.

Q11: IP Rating?

RE: IP66.

Q12: Labeling ?

RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

Q13: Finish color?

RE: Standard colors: Black / White,other colors can be customized, based on MOQ 50PCS.

Q14: Dimming functions?

RE: 1-10V / PWM / Resistance / Timer/ DALI dimmable driver available.

Q15: Is there cheap shipping cost to import to our country?

RE: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much time.For urgent
orders,we suggest via air to airport plus our ship partner send to your door.

Q16:Can we get support if we have our own market position?

RE: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.

More you want to know, please feel free to contact us.

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 26

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 27

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 28

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 29

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 30

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 31

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 32

140LPW Outdoor LED Street Lights 180 Watt IP66 Meanwell Photocell Controller 33

Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
