Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft

  • Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft
  • Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft
  • Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft
  • Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft
Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft
Product Details:
Place of Origin: Shenzhen,China
Brand Name: DUALRAYS
Certification: CE,RoHS,TUV/GS,LM79,LM80
Model Number: DR-TPL020-BG21
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: Negotiable
Packaging Details: Neutral Package,color box package,8PCS/CTN,L670xW440xH200mm
Delivery Time: 5-15 business days
Payment Terms: Western Union, T/T, L/C
Supply Ability: 100000PCS/Month
Contact Now
Detailed Product Description
Rated Power: 20W LEDs Typ/Qty: SMD2835 144pcs
Luminous Flux: 3,200±5% Switching Cycle Before Failure: 100,000
Warranty: 3 Years Power Supply: Boke
Highlight:

led weatherproof batten

,

warm white led batten

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft



LED Tri Proof Light--Detailed Product Description

Model No.: D2 Series Beam Angle: 120°
Power: 20W Protection: IP66,IK10
Driver: DUALRAYS Own-developed flicker-free driver,BOKE DIP switch power adjustable driver Life Span 50,000 hrs
Warranty: 5 Years Sensor(Optional): Daylight Sensor/ Microwave Sensor

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 0





Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 1
D2 Series LED Tri Proof Light--Features
> Highly brightness EPISTAR/SAN‘AN SMD2835 LEDs,energy efficient - up to 160 lm/w;
> 1-10V dimming flicker-free driver;
> Single or Double wiring;
> IP66 and IK10 for all industrial areas of application;
> Eco full plastic light design,save your cost and freight;
> No UV or IR and completely mercury free;
> L80/B10 @ 50.000h;
> Sensor control avaliable;
> No toxic heavy metals, VOC, or mercury were used in the design;
> 5 years warranty;

D2 Series LED Tri Proof Light--Options:
> Driver: DUALRAYS Own-developed flicker-free driver,BOKE DIP switch power adjustable driver.
> Controls and Dimming: Zigbee wireless control / 1-10V Dimming / Daylight sensor,microwave sensor,CCTadjustable,emergency.
> Plug : European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable optional.
> Suspended/Surface mounted/Adjustable installation for option.
> Single or double wiring and connection.
> Customized supported for special projects.
> Sensor: Daylight Sensor/ Microwave Sensor.


Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 2
Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 3



Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 4

Character/Length
2ft
4ft
5ft
Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 5
A
600mm
1200mm
1500mm
B
74mm
74mm
74mm
C
74m
74mm
74mm


Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 6

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 7

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 8
Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 9
Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 10

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 11
(I) Emergency Function


Model No.
Emergency Time (Hours)
Emergency Power (W)
Battery Parameters
DR-TPL020-BG21
3/2/1 hours for option
10W
 7.4V/4400/3000/1500mAh Lithium Battery
DR-TPL040-BG41
3/2/1 hours for option
10W
11.1V/6000/4000/2000mAh Lithium Battery
DR-TPL050-BG51
3/2/1 hours for option
10W
 11.1V/8800/6000/3000mAh Lithium Battery



Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 12
Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 13


Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 14
DALI Device
Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 15

DALI Intelligent Control Diagram
Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 16 Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 17

DALI Intelligent Control Operator Interface
Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 18

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 19
Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 20

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 21

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 22

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 23



Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 24

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 25

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 26

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 27

Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 28


Dualrays D2 Series 20W Slim LED Tri Proof Light 160LmW Damp Proof LED Tube Batten 2ft 29
