Name: 2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: DR-HB240-EG1
Availability: InStock

Home Products HB2.5 UFO LED High Bay

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-HB240-EG1

Payment & Shipping Terms:

Minimum Order Quantity:	2PCS
Price:	Negotiable
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	5-15 Bussiness Day
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000PCS/Month

Contact Now

Detailed Product Description

Rated Power:	240W	LEDs Typ:	SMD3030
Luminaire Efficiency:	Up To 160lm/W	Luminous Flux:	38400±5%
Beam Angle:	120°	IP Rating:	IP65
Power Factor:	PF>0.9	Warranty:	5 Years
Highlight:	led flat panel light fixture , wireless led outdoor flood lights

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate

UFO LED High Bay Features:

> Highly brightness LUXEON SMD3030 LEDs,energy efficient - up to 160 lm/w;

> Die-casting Al for excellent heat dissipation;

> Superior PC reflector-optic for low glare applications,PMMA,glass cover available;

> IP65 and IK10 for all industrial areas of application;

> Driver and housing separated by spacers;

> Adjustable ripple-lens optic with 60°/90°/120° beam angle;

> D-Mark tested for the use in paper production, wood processing etc;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> 5 years warranty;

Item	Description
THD	<10%
SDCM	<5
LED Driver	Meanwell HBG/ELG/HLG,Sosen
LED Chips	SMD3030 LUMILEDS LEDs
Optic Lens	60°/90°/110°
Rated Input Voltage/V	AC100~277V 50/60Hz
Protection Class	class Ⅰ

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate 0

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate 2

> Shipyards;

> Mines;

> Workshops;

> Warehouse;

> Highway toll stations;

> Gas stations;

> Supermarkets;

> Exhibition center;

Character/Power	100W	150W	200W	240W
A	Ø350mm	Ø350mm	Ø420mm	Ø420mm
B	210mm	210mm	220mm	220mm

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate 14

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate 16

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate 17

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate 18

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate 19

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate 20

1.Could Dualrays provide OEM service?

RE: yes,we can offer OEM services four our customers. We can print your own logo on products,packaging and customized packaging box.

2.Is Dualrays a factory or trading company ?

RE: Yes sure, we have our own factory. We focus on intelligent industrial LED luminaires manufacturer, which specialize in developing, producing,sales and service for industrial LED luminaires,mainly service
distributor,wholesaler,contractors,trading companies from Western Europe and Oceania market.

3.Where is Dualrays located?

RE: Dualrays is located in 6th Floor,Building 10, Gangzai Industrial Park, Furong Industrial Park,Xinqiao Industrial District,Shajing,Bao‘an District,Shenzhen 518125, P.R.China,welcome to visit our company.

4.How many years can Dualrays provide for the warranty?

3-5 years from the production date.

5.MOQ ?

Dualrays have no MOQ requirements.Samples orders for trial order is welcome.

2020 Factory UFO High Bay Light IP65 5 Years Warranty Support Driver And housing Separate 22
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
