Name: 5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: DR-HB240-EG2
Availability: InStock

Home Products LED Highbay Light

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-HB240-EG2

Payment & Shipping Terms:

Minimum Order Quantity:	2PCS
Price:	Negotiable
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	5-15 Bussiness Day
Payment Terms:	L/C, T/T, Western Union, Paypal
Supply Ability:	100000PCS/Month

Contact Now

Detailed Product Description

Rated Power:	240W	UGR:	<25
Luminaire Efficiency:	150lm/W	Color Temperature:	WW:3000K NW: 4000K DW:5000K CW: 5700±200K
Beam Angle:	120°,60°	IP Rating:	IP65
Highlight:	high bay led shop lights , wireless led outdoor flood lights

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor

UFO LED High Bay Features:

> IP65 and IK10 for all industrial areas of application;

> Driver and housing separated by spacers;

> Adjustable ripple-lens optic with 60°/90°/120° beam angle;

> D-Mark tested for the use in paper production, wood processing etc;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> 5 years warranty;

> Zigbee wireless control / 1-10V Dimming / Motion sensor / Emergency / DALI control / Daylight sensor.Options:

> Driver: Meanwell HBG(Round),ELG/HLG(Retangle),Sosen

> Reflector : PC reflector with / without cover.pipe mounting

Model No.	DR-HB240-EG2
Rated Power/W	240
Systen Efficiency/LPW	140
Color Temperature	WW:3000±200K NW: 4000±200K DW:5000±200K CW: 5700±200K
Dimming Function	1-10VDC /DALI / PIR Sensor
Protections	Short circuit/Over current/Over voltage/Over temperature
Anti-salty spray	Grade A
Color Index	>80Ra
Beam Angle Options	60°/120° for option
IP/Rating	IP65
AC Input Volage/V	AC100~277V 50/60Hz
Power Factor	PF>0.95
Starting Time	<0.1
LED Driver	Meanwell
UGR	<25
THD	<10%

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor 1

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor 2

> Shipyards;

> Mines;

> Workshops;

> Warehouse;

> Highway toll stations;

> Gas stations;

> Supermarkets;

> Exhibition center;

Character/Power	100W	150W	200W	240W
A	Ø350mm	Ø350mm	Ø420mm	Ø420mm
B	210mm	210mm	220mm	220mm

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor 14

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor 16

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor 17

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor 18

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor 19

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor 20

1.What’s Power factor ?

RE: The active power divided by the apparent power (i.e product of the rms input voltage and rms input current of a driver.)

2.What’s Smart Lighting ?

RE: Automated lighting control using sensors and /or scheduling switches.

3.What’s Watt ?

RE: The unit of electrical power as used by an electrical device during its operation. Many lamps come with rating in watts to indicate their power consumption.

4.How to explain “ZigBee“ ?

RE: A low -power ,low date rate, local area wireless network; ideal for lighting control.

5.How to explain “lumen output “ ?

RE: The total lumens emitted of a light source, system, or solution.

6.How to explain “luminous Efficacy“ ?

RE: A measure of how well a light source products visible light expressed as lumens /Watt.

5 Years Warranty UFO LED High Bay Light CE CB SAA TUV GS 100W 150W 200W 240W With Pluggable Motion Sensor 22
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
