Name: Heat Dissipation LED Street Light IK10 Vibration Grade 180W 10KV / 20KV SPD IP66 With Motion Sensor
Brand: Dualrays Optoelectronics
SKU: DR-ST180-DGXP
Price: 1.00 USD
Availability: InStock
Rating: 4.9 (141 reviews)

Home Products Outdoor LED Street Lights

Heat Dissipation LED Street Light IK10 Vibration Grade 180W 10KV / 20KV SPD IP66 With Motion Sensor

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	Dualrays Optoelectronics
Certification:	CE,RoHS,LM79,LM80
Model Number:	DR-ST180-DGXP

Payment & Shipping Terms:

Minimum Order Quantity:	2PCS
Price:	Negotiable
Packaging Details:	Netural Package,color box package,1PCS/CTN,1040(L)490(W)200(H)mm
Delivery Time:	5-15 business days
Payment Terms:	Western Union, T/T, L/C,Paypal
Supply Ability:	100000PCS/Month

Contact Now

Detailed Product Description

Rated Power:	180W	IP Ratingh:	IP66
Luminaire Efficiency:	140lm/W	Luminous Flux:	25,200±5%
Life Span:	>50,000	Power Supply:	Meanwell/Sosen
High Light:	led cobra head street light , decorative street light

Heat Dissipation LED Street Light IK10 Vibration Grade 180W 10KV / 20KV SPD IP66 With Motion Sensor

Why choosing DUALRAYS:

* Professional team: >10 years experience, own factory, >10 engineers team, powerful production capacity and QC management system, provide both good quality product and service;

* Reliable brand: Built up stable and long-term cooperation with Europe customers, got high prise and trust, and have warehouse in Netherlands for better service;

* Provide DIALux simulation: Send us your parameters of the applications, like distance, height, width, etc, our engineer team will do simulation according to your demand and recommend you the best product;

* All our LED luminaries comply with CE, RoHS standard. TUV, ENEC, VDE, SAA,C-Tick, LM79,LM80 listed for the leading products.

2020 Top sae Heat Dissipation Cobra Led Street Light IK10 Vibration Grade 180W 10KV / 20KV SPD IP66 with motion sensor

Outdoor LED Street Lights Production sepecification:

2020 Hot sale Outpt street led lights with motion serson for highway display

Quick details:

> High brightness LUXEON SMD3030 LEDs,energy efficient - up to 150 lm/w;

> Die-casting Al for excellent heat dissipation;

> Superior PC reflector-optic for low glare applications,and toughened glass protection;

> IP66 and IK10 for road lighting application;

> Driver and housing separated by spacers;

> Professional 50(V)*120(H)°/75(V)*150°(H) optic for option;

> ±10°/-90°(<90W) or ±15°/-90°(>90W) lamp head adjustable;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> Controls and Dimming: 1-10V, DALI, PWM,Zigbee Wireless Dimming for option;

> 10KA SPD,20KA Meanwell SPD optional;

> 3-pins photocell controller ON/OFF,and 7-pins LORA/NEMA socket smart wireless control available;
> Zigbee module (Single-lamp Controller and centralized manager) with software for option;
> DALI driver and DALI Centralized Manager optional;
> Light pole adapter for different poles optional;

> Customized supported for special projects;

* Roadways.

* Avenues.

* Walkways.

* Loading Area.

* Parking lot.

* Playground.
* Sport and Stadium.

Item	Symbol	Description
Model No	/	DR-ST030-DG1	DR-ST060-DG1	DR-ST090-DG1	DR-ST120-DG1	DR-ST150-DG1	DR-ST180-DG1
Rated Power	W	30	60	90	120	150	180
LEDs Typ/Qty	SMD 3030	96	96	512	640	640	640
Luminous Flux	LM	4,200±5%	8,400±5%	12,600±5%	16,800±5%	21,000±5%	25,200±5%
Efficiency	LPW	140	140	140	140	140	140
Color Temperature	CCT/K	WW:3000±200K NW: 4000±200K DW:5000±200K CW: 5700±200K
Dimming Function	/	1-10VDC /PWM / Resistance
Protections	/	Short circuit/Over current/Over voltage/Over temperature
Anti-salty spray	/	Grade A
Color Index	Ra	>70Ra/>80Ra optional
Beam Angle	Degree	120
IP/Rating	/	IP66
AC Input Vol	V	AC95~277V 50/60Hz
Optics	/	Type I /Type III
Power Factor	PF	PF>0.95
Starting Time	s	<0.1
Lumen Maintenance @ 6000 hrs	Hours	>95%
Switching Cycle before Failure	Times	100,000
Life Span	Hours	50,000
Warranty	Years	5 years

30W/60W Version
2020 Hot sale Outpt street led lights with motion serson for highway display

90W,120W/150W/180W Version

2020 Hot sale Outpt street led lights with motion serson for highway display

Zigbee Wireless Intelligent Control Diagram

Zigbee Wireless Intelligent Control Operator Interface
2020 Hot sale Outpt street led lights with motion serson for highway display

IP66 150W Recessed Retrofit LED Canopy Light For Gas Station

140LPW Efficiency Led Outside Flood Lights 60W LED Source Multi Beam Angle
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul! 2020 Hot sale Outpt street led lights with motion serson for highway display
Packaging Information
