Place of Origin: | Shenzhen,China |
Brand Name: | DUALRAYS |
Certification: | CE,ROHS,TUV/GS,LM79,LM80,SAA |
Model Number: | DR-HB200-EGXP |
Minimum Order Quantity: | 1pcs |
---|---|
Price: | $55.66/pcs |
Packaging Details: | Netural Package/OEM and ODM Package Available |
Delivery Time: | 5-15 business days |
Driver: | Meanwell | LED Chips: | Lumiled SMD3030 |
---|---|---|---|
Warranty: | 5 Years | Life Span: | L80>50,000HRS |
High Light: | 150W UFO High Bay Lighting,SMD3030 UFO High Bay Lighting,SAA LED High Bay Light |
High Bay Super Durable for Industrial Application, High Lumen Efficiency
a. Luxeon SMD3030 LEDs, chips lumen up to 140lm/w, LM80 listed;
b. LED Driver: Meanwell, Sosen;
c. L80>65,000hrs;
d. Optic lens: 60°/90°/120°, dialux lighting design service for free, IES file free to offer;
e. Rated power: 100W/ 150W/ 200W/ 240W;
f. Intellegent and Dimming function optional: 1-10V/ DALI/ Zigbee;
g. Sensor optional: Motion sensor, daylight sensor
Model No. | DR-HB100-EGXP | DR-HB150-EGXP | DR-HB300-EGXP |
System Watts/W | 100W | 150W | 300W |
System Efficiency/LPW | 14.000±5% | 21.000±5% | 42.000±5% |
Efficiency/ lm/w | 140LM/W | ||
Rated Input Voltage/V | AC100~277V 50/60Hz | ||
LEDs Light Source | SMD3030 | ||
SDCM | <5 | ||
CCT/K | 3000K/4000K/5000K/5700K/6500K | ||
CRI/Ra | >80Ra (>70Ra for Option) | ||
Power Factor | >0.95 | ||
THD | <10% | ||
Beam Angle(Optional) | 60°/90°/110° | ||
UGR | <25 | ||
Surge Protection | 6~10KV SPD built in Driver,Exterior SPD 10KV() or 20KV Meanwell Optional | ||
LED Driver | Meanwell HBG/ ELG/ HLG, Sosen | ||
IP Rating | IP65 | ||
Dimming(Optional) | 0/1-10V/DALI/Zigbee | ||
Sensor(Optional) | Pluggable Motion Sensor, Daylight sensor | ||
Emergency(Optional) | Available | ||
Protection Class | ClassⅠ | ||
Finishing Color(Optional) | Black RAL9017 / White RAL9016 | ||
Material | Aluminum+PC | ||
Lifespan/hrs | >50.000 Hrs (Ta=30℃@L70) | ||
Operation Temp/℃ | -40°C to + 50°C(-40°F to 122°F) | ||
Storage Temp/℃ | -40°C to + 65°C(-40°F to 149°F) | ||
Dimension/mm | Φ350*210mm | ||
Installation(Optional) | Loop Hanging, Ceiling Mounting, Wall Mounting,Pipe Mounting | ||
Certificate | CE(EMC+LVD), RoHS, TUV/GS, D-Mark, SAA, RCM Available; |
Character/Power | 100W | 150W | 200W | 240W | |
A | Ø350mm | Ø350mm | Ø420mm | Ø420mm | |
B | 210mm | 210mm | 220mm | 220mm |
DALI Device
DALI Intelligent Control Diagram
DALI Intelligent Control Operator Interface
