2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant

  • 2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant
  • 2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant
  • 2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant
  • 2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant
  • 2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant
2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant
Product Details:
Place of Origin: Shenzhen,China
Brand Name: DUALRAYS
Certification: CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number: DR-HB100-CGXP
Payment & Shipping Terms:
Minimum Order Quantity: 2PCS
Price: Negotiation
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 Bussiness Day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000PCS/Month
Contact Now
Detailed Product Description
CCT: 3000K~6500K THD: <10%
Beam Angle: 60°/90°/110°(option) Dimming(optional): 0/1~10V/Zigbee
Material: Aluminum CRI: >80Ra/(>70Ra For Option )
High Light:

led flat panel light fixture

,

wireless led outdoor flood lights



2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant

Products(HB3) Description:

> Highly brightness SAN‘AN SMD3030 LEDs,energy efficient - up to 140 lm/w;
> Die-casting Al for excellent heat dissipation;
> Superior PC reflector-optic for low glare applications;
> IP65 and IK08 for all industrial areas of application;
> DUALRAYS own-developed built-in driver,slim design,compact and durable;
> Adjustable ripple-lens optic with 60°/90°/120° beam angle;
> D-Mark tested for the use in paper production, wood processing etc;
> No UV or IR and completely mercury free;
> L80/B10 @ 50.000h;
> 5 years warranty;
> Driver: DUALRAYS Own-developed built-in driver,slim design,durable and compact.
> Controls and Dimming
·Zigbee wireless control / 1-10V Dimming / Daylight sensor.
> Reflector : PC reflector with / without cover.pipe mounting.
> Installation: loop hanging, ceiling mounting, wall mounting,
> Customized supported for special projects.

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 0
> Factories / Warehouses /Workshops
> Exhibitions & showrooms
> Barns and riding halls
> High rooms and halls
> Traditional lamp replacement
2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 1
LEDs light source                               SMD3030
CCT/K 3000K/4000K/5000K/5700K/6500K
SCDM <5
CRI(Ra) >80Ra(>70Ra for option)
THD <10%
IP Rating IP65
Power Factory >0.95
Beam Angle 60°/90°/110°(for option)
UGR <25
LED Driver Dualrays-develop built-in driver
Dimming (Optional) 0/1~10V/Zigbee
System Efficiency/lpw 140LPW
IK Rating  IK08
Lifespan >50000hours
Operation Temp℃ -40℃~60℃
Sensor (option) Daylights sensor
Systems Watt 100W

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 2

Character/Power
100W
150W
200W

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 3
A
Ø322mm
Ø322mm
Ø322mm

B
128mm
128mm
128mm



2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 4



2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 5

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 6
2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 7
2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 8

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 9
2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 10
2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 11
2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 12





DALI Device


DALI Intelligent Control Diagram
2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 13 2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 14


DALI Intelligent Control Operator Interface



2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 15
2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 16

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 17

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 18

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 19

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 20
2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 21

2020 UFO High Bay Light IP 65 Support Special Project With CE CB ASS For Plant 22
