| Place of Origin: | Shenzhen,China |
| Brand Name: | DUALRAYS |
| Certification: | CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available |
| Model Number: | DR-TP050-BHG2XPX |
| Minimum Order Quantity: | 50pcs |
|---|---|
| Price: | negotiate |
| Packaging Details: | Netural Package/OEM and ODM Package Available |
| Delivery Time: | 8-15 Business Day |
| Payment Terms: | L/C, T/T, Western Union, paypal |
| Supply Ability: | 50000PCS/Month |
| Model No.: | DR-TP020-BHG2XPX | CCT/K: | 5000K For Standard (3000K/4000K/5700K/6500K Optional) |
|---|---|---|---|
| IP Rating: | IP65 | IK Level: | IK08 |
| Material: | PC+AL | Lifespan/hrs: | 52.000 Hrs (Ta=30℃@L70) |
| System Efficiency/LPW: | 120LPW / 140LPW Optioanl | Installation: | Suspension / Ceiling Mounting Optional |
D2.5 LED Triproof Lighting Multiple Installations Suspension Wal Hi-Slim & Buckle End Cap Design For Labor Cost Saving
Features:
Specification:
| Model No. | DR-TP020-BHG2XPX | DR-TP030-BHG4XPX | DR-TP040-BHG4XPX | DR-TP040-BHG5XPX | DR-TP050-BHG5XPX |
| System Watts/W | 20W | 30W | 40W | 40W |
50W
|
| System Efficiency/LPW | 120LPW / 140LPW Optioanl | ||||
| Lumen Output/lm | 2.400/2.800±5% | 3.600/4.200±5% | 4.800/5.600±5% | 4.800/5.600±5% | 6.000/7.000±5% |
| Rated Input Voltage/V | AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional) | ||||
| LEDs Light Source | SMD2835 | ||||
| SDCM | <6 | ||||
| CCT/K | 5000K for Standard (3000K/4000K/5700K/6500K Optional) | ||||
| CRI/Ra | >80Ra (>70Ra for Option) | ||||
| Power Factor | >0.94 | ||||
| THD | <10% | ||||
| Beam Angle(Optional) | 120° | ||||
| UGR | <22 | ||||
| LED Driver | DUALRAYS Own Developed High PF Driver | ||||
| IP Rating | IP65 | ||||
| IK Level | IK08 | ||||
| Dimming(Optional) | 1-10V | ||||
| Sensor(Optional) | No | ||||
| Emergency(Optional) | No | ||||
| Protection Class | ClassⅠ | ||||
| Finishing Color(Optional) | White RAL9016 Optional | ||||
| Material | PC+AL | ||||
| Lifespan/hrs | 52.000 Hrs (Ta=30℃@L70) | ||||
| Operation Temp/℃ | 40°C to + 50°C(-40°F to 122°F) | ||||
| Storage Temp/℃ | - 40°C to + 65°C(-40°F to 149°F) | ||||
| Installation(Optional) | Suspension / Ceiling Mounting Optional | ||||
| Certificate | CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available | ||||
Dimsion:
|
Character/Length
|
2ft
|
4ft
|
5ft
|
|
|
A
|
602mm
|
1202mm
|
1502mm
|
|
|
B
|
73.5mm
|
73.5mm
|
73.5mm
|
|
|
C
|
29mm
|
29mm
|
29mm
|
|
|
|
|
|
|
Optical & Photometric:
Installation:
RISK OF PERSONAL INJURY – READ and follow all WARNINGS and installation instructions.
Keep or give to the owner for future reference.
Risk of cuts: Wear gloves to prevent cuts or abrasions when removing from carton, handling, installing, and maintaining this product.
Risk of electric shock: This product must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the product and the hazards involved.
Risk of Fire: Minimum 194°F supply conductors. Consult a qualifed electrician to ensure correct branch circuit conductor. DUALRAYS® assumes no responsibility for claims arising out of improper or careless Installation or handling of this product.
Details Demo:
Shipment&Package:
|
Model No.
|
Net Weight/Kg
|
Outer Carton Size/mm
|
Gross Weight/Kg
|
QTY”/CTN
|
|
DR-TP020-BHG2XP
|
14.9 |
700*305*210
|
15.8
|
12PCS/CTN
|
|
DR-TP030-BHG4XP
|
18.4
|
1300*305*210
|
19.8
|
12PCS/CTN
|
|
DR-TP040-BHG4XP
|
20.2
|
1300*305*210
|
21.6
|
12PCS/CTN
|
|
DR-TP040-BHG5XP
|
24.2
|
1600*305*210
|
25.8
|
12PCS/CTN
|
|
DR-TP050-BHG5XP
|
25.3
|
1600*305*210
|
26.8
|
12PCS/CTN
|
