140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications

140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications

  • 140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications
  • 140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications
  • 140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications
  • 140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications
  • 140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications
Product Details:
Place of Origin: Shenzhen,China
Brand Name: DUALRAYS(OEM available)
Certification: CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number: DR-HB150-XGXP
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs for Sample Order welcome
Price: Please inquiry for updated price
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 Bussiness Day
Payment Terms: L/C, T/T, Western Union, paypal
Supply Ability: 50000PCS/Month
Contact Now
Detailed Product Description
Input Voltage: AC100~277v 50/60Hz Driver: Dualrays Built-in
LED Source: SMD2835(1w) CRI: >70Ra/>80Ra
Power Factor: 0.95 CCT: WW:3000±200K NW: 4000±200K DW:5700±200K CW: 6500±200K
Life Span: >50,000 H Guarantee: 5 Years
Material: Die-Cast Aluminum + Tempered Glass/PC Package: Normal Export Carton Box
High Light:

IK08 UFO LED High Bay Light

,

UFO LED High Bay Light 150W

,

SMD3030 LED High Bay Lamp

LED UFO high bay light 150W 140Lpw IP65 excellent heat dissipation



140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 0

140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 1
Options:

> Driver: DUALRAYS Non-isolated Driver;
> Controls and Dimming: 1-10V, Motion sensor,Daylight sensor,Zigbee and Emergency;
> Reflector : PC reflector / Al reflector;
> Lens : 60°/90° (with Pearl Lens)/120° (with Toughened Glass Cover) beam angle optional;
> Installation: Loop Hanging, Ceiling Mounting, Wall Mounting;

140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 2
> Factories / Warehouses / Supermarket
> Exhibitions / Showrooms / Animal Farm
> Barns and Riding Halls / Logistic Center
> High Rooms and Halls / Stadium / Chemical Plant
> Traditional lamp replacement


140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 3

Model No.
DR-HB100-XGXP DR-HB150-XGXP DR-HB200-XGXP
System Watts/W
100W 150W 200W
System Efficiency/LPW
140LPW
Lumen Output/lm
14.000±5% 21.000±5% 28.000±5%
Rated Input Voltage/V
AC100~277V, 50/60Hz
LEDs Light Source
SMD3030
SDCM
<5
CCT/K
5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra
>70Ra (>80Ra for Option)
Power Factor
>0.95
THD
<10%
Beam Angle(Optional)
60°/90°/120°
UGR
<25
Surge Protection
3.75~4KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver
DUALRAYS Own-developed High PF Non-isolated Driver
IP Rating
IP65
Dimming(Optional)
0/1-10V/Zigbee
Sensor(Optional)
Motion Sensor,Daylight Sensor
Emergency(Optional)
Available (30W @ 3Hrs for Standard)
Protection Class
ClassⅠ
Finishing Color(Optional)
Black RAL9017(Standard) / White RAL9016 Optional
Material
Aluminum+PC (Toughened Glass Cover Optional)
Lifespan/hrs
60.000 Hrs (Ta=30℃@L70)
Operation Temp/℃
40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃
- 40°C to + 65°C(-40°F to 149°F)
Installation(Optional)
Loop Hanging, Ceiling Mounting, Wall Mounting
Certificate
CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available





140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 4

Character/Power
100W
150W
200W
240W
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 5
A / mm
Φ250
Φ300
Φ345
Φ345
B / mm
178
181
183
183


140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 6

140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 7

140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 8
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 9

140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 10
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 11
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 12140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 13

DALI Device
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 14

DALI Intelligent Control Diagram
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 15 140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 16


DALI Intelligent Control Operator Interface
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 17


140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 18
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 19
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 20
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 21

140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 22

Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-HB100-CGXP
2.2
320*320*165
2.9
1PCS/CTN
DR-HB150-CGXP
2.4
355*350*165
3.1
1PCS/CTN
DR-HB200-CGXP
2.5
410*410*175
3.3
1PCS/CTN
DR-HB240-CGXP
2.9
410*410*175
3.8
1PCS/CTN





FAQ



Q1:What should I pay attention to when buying LED high bay lights?
RE:When buying LED high bay lights, if you look at the price of LED high bay lights first, or put the price first, you are very wrong, because the price is the most sensitive one that can influence personal thoughts. Nowadays, manufacturers in all walks of life are mixed, with intermediary traders stepping in. This has led to market chaos, disordered prices, and uneven quality.



Analysis of the market based on more than ten years of experience: the situation encountered by ordinary customers; there are low prices that do not dare to buy, high prices are reluctant to buy, sellers are too close to buy, and the more they are, the less they know how to buy . The main reason for this is because we still don't know what to pay attention to when buying LED high bay lights.



1: Look at the quality of LED high bay lights, which is the configuration. First of all, what brand does the LED high bay light chip use? Imported first-line brands have high luminous efficiency, long life, low luminous decay, and stability. Second, look at the power supply. A poor quality power supply is basically insufficient power, that is, if you take a 100w lamp, it is actually 40-50w, which will affect the life of the lamp. Then look at the material of the lamp housing. The price of the lamp also depends on the amount and purity of the aluminum used. Imported pure aluminum is used. The heat sink is large. The use of aluminum is naturally more. Only the material used can ensure the heat dissipation effect of the lamp. In addition, the electrical box of the lamp should be made of pure aluminum, and some cast iron has poor heat dissipation.



2: Talk to the supplier about the company. Observe whether the supplier is professional through the conversation with each other, so as to ensure the authenticity of every accessory used and not cut corners. Some small companies sell you LED high bay lights with low configuration and low prices. After a few months of use, the lights are broken. When you go to them, some companies have closed down or changed their names to continue to deceive consumers.



3: Negotiate prices with suppliers. Ask the supplier's price system, not the specific product price, so that you can clearly understand the price space, so you can see how much space you need for the product price. Then put forward the product and inform the demand of the product. The quotation is the supplier's business. With so much discussion, the supplier can only make a reasonable price.



4: place orders in time. Don’t hesitate after the negotiation, be fast, because this way the supplier will respond to you quickly; if you slowly buy the order, the supplier will slowly prepare the goods for you. The production of LED high bay lights is always available. Made to order. The supplier will definitely have many customers, and the supplier must arrange the goods in order according to the pace of things, so the supplier will be faster if you are faster!



140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 23
140lpw 150w HB4.5 High Bay Light According To CE Standard For Warehouses Supermarket And Other Applications 24
