Name: DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional
Brand: DUALRAYS
SKU: DR-HB300-EG2
Price: 1.00 USD
Availability: InStock
Rating: 4.7 (109 reviews)

Home Products UFO LED High Bay Light

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-HB300-EG2

Payment & Shipping Terms:

Minimum Order Quantity:	2PCS
Price:	Negotiated After Inquiry
Packaging Details:	Netural Package/OEM and ODM Package Available
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50000PCS/Month

Contact Now

Detailed Product Description

Delivery Time:	5 To 7 Business Days For Samples,12 To 15 Business Days For Bulk Orders Or Negotiated	Cable:	31.0mm2 Or 51.0mm2(Dimming) Or Customized
Europe Warehouse:	Netherlands	OEM Service:	Private Label Free Of Charge For Quantity Above 100PCS Per Model
Shipment Term:	Ex-Works For Order Value＜ 50,000USD,FOB Shenzhen For Order Value ≥ 50,000 USD	Plug:	European Or Australia Plug Optional
Working Lifetime:	50000 Hours	Lifespan:	>50.000 Hrs (Ta=30 @L70)
Finishing Color(Optional):	Black RAL9017 / White RAL9016	Installation Type:	Loop Hanging, Ceiling Mounting, Wall Mounting,Pipe Mounting
Certificate:	CE(EMC+LVD),RoHS,TUV/GS ,D-Mark,SAA,RCM Available	Surge Protection:	6~10KV SPD Driver,Exterior SPD 10KV() Or 20KV Meanwell Optional
High Light:	led flat panel light fixture , wireless led outdoor flood lights

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 0

Model No.	DR-HB100-EGXP	DR-HB150-EGXP	DR-HB200-EGXP	DR-HB240-EGXP	DR-HB300-EGXP
System Watts/W	100W	150W	200W	240W	300W
System Efficiency/LPW	140LPW
Lumen Output/lm	14.000±5%	21.000±5%	28.000±5%	33.600±5%	42.000±5%
Rated Input Voltage/V	AC100~277V 50/60Hz
LEDs Light Source	SMD3030
SDCM	<6
CCT/K	3000K/4000K/5000K/5700K/6500K

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 1

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 3

> Highly brightness LUXEON SMD3030 LEDs,energy efficient - up to 160 lm/w;

> Die-casting Al for excellent heat dissipation;

> Superior PC reflector-optic for low glare applications,PMMA,glass cover available;

> IP65 and IK10 for all industrial areas of application;

> Driver and housing separated by spacers;

> Adjustable ripple-lens optic with 60°/90°/120° beam angle;

> D-Mark tested for the use in paper production, wood processing etc;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> 5 years warranty;

Options:

> Driver: Meanwell HBG(Round),ELG/HLG(Retangle),Sosen

> Controls and Dimming

·Zigbee wireless control / 1-10V Dimming / Motion sensor / Emergency / DALI control / Daylight sensor.

> Reflector : PC reflector with / without cover.pipe mounting.

> Installation: loop hanging, ceiling mounting, wall mounting,

> Customized supported for special projects.

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 5

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 6

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 7

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 8

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 9

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 10

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 11

DUALRAYS HB5 IP65 IK08 UFO LED High Bay European Australia Plug with Customzied Cable Length Optional 12
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
