Name: UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: DR-HB200-CGXP
Availability: InStock

Home Products HB2.5 UFO LED High Bay

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-HB200-CGXP

Payment & Shipping Terms:

Minimum Order Quantity:	2PCS
Price:	Negotiable
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	5-15 Bussiness Day
Payment Terms:	L/C, T/T, Western Union, Paypal
Supply Ability:	100000PCS/Month

Contact Now

Detailed Product Description

Power Effciency/LPW:	140LPW	Power Factor:	>0.95
Operation Temperature:	-40℃~+50℃	CRI（Ra）:	>80Ra(>70Ra For Option)
Warranty:	5 Years	Material:	Aluminium + PC
IP Rating:	IP65	Life Span:	50,000 Hours
Highlight:	led flat panel light fixture , wireless led outdoor flood lights

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model

UFO LED High Bay Light Production Advantage:

> DUALRAYS own-developed built-in driver,slim design,compact and durable;

> Adjustable ripple-lens optic with 60°/90°/120° beam angle;

> IP65 and IK08 for all industrial areas of application;

> Die-casting Al for excellent heat dissipation;

> Customized supported for special projects.

> 5 years warranty;

LEDs Light Source	SMD3030
Lumen Output/lm	28000±5%
Model NO.	DR-HB200-CGXP
CRI(Ra)	>80Ra(>70Ra for option)
Input Wattage	AC 100~277V 50/60Hz
IP Rating	IP65
System Efficiency/LPW	140LPW
IK Rating	IK08
THD	<10%
Operation Temp℃	-40℃~60℃
Sensor (Optional)	Daylights Sensor
Systems Wattage	200W

> Factories / Warehouses /Workshops

> Exhibitions & showrooms

> Barns and riding halls

> High rooms and halls

> Traditional lamp replacement
UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 1

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 2

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 3

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 5

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 7

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 8

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 9

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 16

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 17

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 18

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 19

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 20

1.What’s Power factor ?

RE: The active power divided by the apparent power (i.e product of the rms input voltage and rms input current of a driver.)

2.What’s Smart Lighting ?

RE: Automated lighting control using sensors and /or scheduling switches.

3.What’s Watt ?

RE: The unit of electrical power as used by an electrical device during its operation. Many lamps come with rating in watts to indicate their power consumption.

4.How to explain “ZigBee“ ?

RE: A low -power ,low date rate, local area wireless network; ideal for lighting control.

5.How to explain “lumen output “ ?

RE: The total lumens emitted of a light source, system, or solution.

6.How to explain “luminous Efficacy“ ?

RE: A measure of how well a light source products visible light expressed as lumens /Watt.

UFO High Bay Light 100W 150W 200W Support Loop Hanging Ceiling Mounting Wall Mounting Instaltion Model 22

Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
