DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-HB240-EG2

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	Negotiated After Inquiry
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	5-15 Bussiness Day
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	50000PCS/Month

Contact Now

Detailed Product Description

Installation(Optional):	Loop Hanging, Ceiling Mounting, Wall Mounting,Pipe Mounting	Certificate:	CE(EMC+LVD),RoHS,TUV/GS ,D-Mark,SAA,RCM Available
Storage Temp/℃:	-40°C To + 65°C(-40°F To 149°F)	Operation Temp/℃:	-40°C To + 50°C(-40°F To 122°F)
Lifespan/hrs:	>50.000 Hrs (Ta=30 @L70)	Material:	Aluminum+PC
Finishing Color(Optional):	Black RAL9017 / White RAL9016	Protection Class:	ClassⅠ
Sensor(Optional):	Pluggable Motion Sensor,Daylight Sensor	Emergency(Optional):	Available
High Light:	led flat panel light fixture , high bay led shop lights

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 0

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 1

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 2

Model No.	DR-HB100-EGXP	DR-HB150-EGXP	DR-HB200-EGXP	DR-HB240-EGXP	DR-HB300-EGXP
System Watts/W	100W	150W	200W	240W	300W
System Efficiency/LPW	140LPW
Lumen Output/lm	14.000±5%	21.000±5%	28.000±5%	33.600±5%	42.000±5%
Finishing Color(Optional)	Black RAL9017 / White RAL9016
Protection Class	ClassⅠ
LED Driver	Meanwell HBG/ELG/HLG,Sosen
Surge Protection	6~10KV SPD Driver,Exterior SPD 10KV() or 20KV Meanwell Optional
Rated Input Voltage/V	AC100~277V 50/60Hz
LEDs Light Source	SMD3030
SDCM	<6
CCT/K	3000K/4000K/5000K/5700K/6500K

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 3

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 6

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 12
> Highly brightness LUXEON SMD3030 LEDs,energy efficient - up to 160 lm/w;

> Die-casting Al for excellent heat dissipation;

> Superior PC reflector-optic for low glare applications,PMMA,glass cover available;

> IP65 and IK10 for all industrial areas of application;

> Driver and housing separated by spacers;

> Adjustable ripple-lens optic with 60°/90°/120° beam angle;

> D-Mark tested for the use in paper production, wood processing etc;

> No UV or IR and completely mercury free;

> L80/B10 @ 50.000h;

> 5 years warranty;

Options:

> Driver: Meanwell HBG(Round),ELG/HLG(Retangle),Sosen

> Controls and Dimming

·Zigbee wireless control / 1-10V Dimming / Motion sensor / Emergency / DALI control / Daylight sensor.

> Reflector : PC reflector with / without cover.pipe mounting.

> Installation: loop hanging, ceiling mounting, wall mounting,

> Customized supported for special projects.

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 13

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 14

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 15

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 16

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 17

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 18

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 19

DUALRAYS HB5 UFO High Bay Light With 1-10v DALI Motion Sensor Daylight Sensor Zigbee And Emergency 20
