Name: LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function
Brand: DUALRAYS LIGHTING Co.,LTD.
SKU: DR-HB150-EG1
Availability: InStock

Home Products HB2.5 UFO LED High Bay

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	DUALRAYS
Certification:	CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number:	DR-HB150-EG1

Payment & Shipping Terms:

Minimum Order Quantity:	2PCS
Price:	Negotiable
Packaging Details:	Netural Package/OEM and ODM Package Available
Delivery Time:	5-15 Bussiness Day
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000PCS/Month

Contact Now

Detailed Product Description

Warranty:	5 Years	Power:	150W
CCT:	WW:3000±200K NW: 4000±200K DW:5000±200K CW: 5700±200K	LED Light Source:	SMD3030
CIR:	>80Ra	Life Span:	50000H
Highlight:	led flat panel light fixture , high bay led shop lights

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function

UFO LED High Bay Light Description:

LEDs light source	SMD3030
CRI	>80Ra(>70Ra for option)
IP Rating	IP65
IK Rating	IK10
Lifespan	>50000hours
Operation Temp℃	-40℃~60℃
Sensor (option)	Motion Sensor/Daylight Sensor
Systems Wattage	150W

Features:

* LUMILEDS LUXEON High Brightness SMD3030 LEDs,SOSEN/Meanwell Driver;

* IP65 Protection;

* 60°/90°(with lens)/120°(without lens) beam angle optional;

* IP65 Protection;

* D-Mark tested for the use in paper production,wood processing etc with toughened glass;
* Multiple installations: loop hanging, ceiling mounting, wall mounting,pipe mounting;
* Various intelligent control: 1-10V, DALI, Motion sensor, Daylight sensor,Zigbee and Emergency;
* Customized supported for special projects;

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function 0

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function 2

> Shipyards;

> Mines;

> Workshops;

> Warehouse;

> Highway toll stations;

> Gas stations;

> Supermarkets;

> Exhibition center;

Character/Power	100W	150W	200W	240W
A	Ø350mm	Ø350mm	Ø420mm	Ø420mm
B	210mm	210mm	220mm	220mm

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function 14

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function 16

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function 17

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function 18

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function 19

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function 20

Q1: Do you offer OEM or ODM?

RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:

1. We can provide you with our present products with your own label;

2. We can modify our products as your request;

3. We can even develop totally new products based on your design;

Q2: What‘re the chips and drivers used?

RE: High brightness LUMILEDS LEDs light source,Meanwell/Sose drivers for standard configuration;

Q3: What is the CRI?

RE: Ra>80 for standard.

Q4: IP Rating?

RE: IP65.
Q5: Labeling ?

RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

LED UFO High Bay Light IP65 With Motion Sensor and Emergency Function 22
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
