Home ProductsSMD LED Floodlight

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light

  • Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light
  • Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light
Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light
Product Details:
Place of Origin: Shenzhen,China
Brand Name: DUALRAYS
Certification: CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number: DR-FL200-CG2
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Please inquiry for laterst price
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 Bussiness Day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50000PCS/Month
Contact Now
Detailed Product Description
Housing: Die-casting Al Power Factor: >0.92
Equivalent: 500W Traditional Lamp CRI: >80
Cable: 3*0.75 Driver Solution: Non-Isolated
High Light:

high bay led shop lights

,

wireless led outdoor flood lights

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 0



> 200W LED Flood Light Flat 13500LM for Outdoor Security and Decoration

> Built-in Plug and Play Motion Sensor with Compact Structure;

> L70/B20(25℃)65.000h;

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 1

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 2

Model No. DR-FL050-CGX DR-FL100-CGX DR-FL150-CGX DR-FL200-CGX DR-FL300-CGX
System Watts/W 50W 100W 150W 200W 300W
System Efficiency/LPW 6.800±5% 13.500±5% 20.000±5% 27.000±5% 33.200±5%
Efficiency/ lm/w 135LM/W
Rated Input Voltage/V AC100~277V 50/60Hz
LEDs Light Source SMD3030
SDCM <5
CCT/K 3000K/4000K/5000K/5700K/6500K
CRI/Ra >80Ra (>70Ra for Option)
Power Factor >0.95
THD <10%
Beam Angle(Optional) 30° / 60° / 90° / 120°
UGR <25
Surge Protection 6~10KV SPD built in Driver,Exterior SPD 10KV() or 20KV Meanwell Optional
LED Driver Sosen, Meanwell ELG/ HLG
IP Rating IP65
Dimming(Optional) 0/1-10V/DALI/Zigbee
Emergency(Optional) Available
Protection Class ClassⅠ
Material Aluminum+PC
Lifespan/hrs >62.000 Hrs (Ta=30℃@L70)
Operation Temp/℃ -40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃ -40°C to + 65°C(-40°F to 149°F)
Installation(Optional) Ceiling Mounting, Wall Mounting, Ground Mounting
Certificate CE(EMC+LVD), RoHS, TUV/GS, D-Mark, SAA, RCM Available;
Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 3
Character/Power
100W
150W
200W
240W
300W
Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 4
A / mm
389
389
437
493
582
B / mm
297
297
346
379
444
C / mm
57
57
57
57
60

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 5
Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 6
Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 7
Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 8Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 9
Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 10

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 11

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 12

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 13

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 14

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 15
Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-FL050-CGXX
3.6
355*350*165
4.5
1PCS/CTN
DR-FL100-CGXX
3.8
355*350*165
4.7
1PCS/CTN
DR-FL150-CGXX
4.5
415*410*175
5.8
1PCS/CTN
DR-FL200-CGXX
5.7
475*470*195
7.3
1PCS/CTN
DR-FL300-CGXX
9.3
475*470*195
11.5
1PCS/CTN

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 16
Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 17

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 18

Lumileds 3030 Chips 200W Industrial Hall Using LED Flood Light 19
