200W Stadium LED Sports Ground Floodlights IP66 150LPW Different Beam Angle SMD3030

200W Stadium LED Sports Ground Floodlights IP66 150LPW Different Beam Angle SMD3030

  • 200W Stadium LED Sports Ground Floodlights IP66 150LPW Different Beam Angle SMD3030
  • 200W Stadium LED Sports Ground Floodlights IP66 150LPW Different Beam Angle SMD3030
  • 200W Stadium LED Sports Ground Floodlights IP66 150LPW Different Beam Angle SMD3030
  • 200W Stadium LED Sports Ground Floodlights IP66 150LPW Different Beam Angle SMD3030
200W Stadium LED Sports Ground Floodlights IP66 150LPW Different Beam Angle SMD3030
Product Details:
Place of Origin: Shenzhen,China
Brand Name: DUALRAYS
Certification: CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number: DR-FL200-CGXP
Payment & Shipping Terms:
Minimum Order Quantity: 2PCS
Price: Please inquiry for the latest price
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 Bussiness Day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50000PCS/Month
Contact Now
Detailed Product Description
Warranty: 5 Years Power Factor: >0.95
CRI: >80 CCT/K: 3000K,4000K,5000K,5700K
Power: 50W/100W/150W/200W/250W/300W Beam Angle: 10°/25°/45°/60°/90°/30*70°/80*140°/60*130°
High Light:

high mast flood lights

,

led stadium floodlights

200W Stadium LED Sports Ground Floodlights IP66 150LPW Different Beam Angle SMD3030



LED Sports Ground Floodlights Feature:

* Full Al heat sink structure,processional optics design,>50% efficiency higher than the general flood light in the market;

* High Color Rendering Index (CRI>80);

* ±90° adjustable European bracket for actual lighting direction;

* Module structure design concept,convenient for assemble and dis-assemble,maintenance,secure and reliable;

* Constant voltage or constant current output, quick responds,no flicker, lighting protection, PFC function available;

* Die-casting Al for excellent heat dissipation;



Warranty: 5 Years IP Rating: IP66
Op. Temp.: -40°C to + 50°C(-40°F to 122°F) Driver: Meanwell ELG/HLG,Sosen
Driver Type: Flicker-Free Efficacy: 150Lm/W (± 5%)
Power Factor: >0.95 IVR: AC100 - 277V 50/60Hz
Power: 200W Luminous Flux: 30,000Lm (±5%)
LED Chip: Lumileds Chip Type: SMD 3030
CRI: >70Ra (>80Ra for Option) Lifespan: >50,000 Hours



After-Sales Service
a. 3 to 5 years quality warranty with lifelong maintenance.
b. Spare parts: necessary spare parts are provided together with products to customers.
c. Free technical training: integrative and normative technology training is available for free to customers by our technical personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.
d. Telephone investigation: our after-sales team will phone the user every month during the warranty period to follow up the working condition of the products, and to discover and solve problems, if necessary.
e. Software upgrade: lifelong maintenance of controlling system, incessant improvement of the system functions and continuous software upgrades

Outdoor IP65 50W 120LPW SMD3030 led security flood light 0
Outdoor IP65 50W 120LPW SMD3030 led security flood light 1

Options:
> Driver: Sosen,Meanwell ELG/HLG driver;
> Controls and Dimming: 1-10V, DALI,PWM,Zigbee;
> Surge Protection Device: Meanwell SPD-20 20KV Surge Protector;
> Lens : Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV;
> Microwave Motion Sensor;

Outdoor IP65 50W 120LPW SMD3030 led security flood light 2
> Airports & Harbors
> Billboard illumination
> Large recreational sports facilities
> Industrial areas & Landscape buildings
> Roundabouts and motorway junctions

Outdoor IP65 50W 120LPW SMD3030 led security flood light 3
Model No.
DR-FL050-CGXX DR-FL100-CGXX DR-FL150-CGXX DR-FL200-CGXX DR-FL300-CGXX
System Watts/W
50W 100W 150W 200W
300W
System Efficiency/LPW
120~125LPW
Lumen Output/lm
6.500±5% 12.500±5% 18.750±5% 25.000±5% 37.500±5%
Rated Input Voltage/V
AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
LEDs Light Source
SMD3030
SDCM
<5
CCT/K
5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra
>70Ra (>80Ra for Option)
Power Factor
>0.95
THD
<10%
Beam Angle(Optional)
Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV beam angle optional
UGR
<25
Surge Protection
6~10KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver
Sosen,Meanwell ELG / HLG Optional
IP Rating
IP65
Dimming(Optional)
1-10V, DALI,PWM,Zigbee for Option
Safety Protection Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Sensor (Optional) Motion Sensor
Protection Class
ClassⅠ
Finishing Color(Optional)
Black RAL9017(Standard) / White RAL9016 Optional
Material
Aluminum+Toughened Glass
Lifespan/hrs
62.000 Hrs (Ta=30℃@L70)
Operation Temp/℃
40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃
- 40°C to + 65°C(-40°F to 149°F)
Switching Cycles 100,000 Times
Certificate
CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

Outdoor IP65 50W 120LPW SMD3030 led security flood light 4
Character/Power
100W
150W
200W
240W
300W
Outdoor IP65 50W 120LPW SMD3030 led security flood light 5
A / mm
389
389
437
493
582
B / mm
297
297
346
379
444
C / mm
57
57
57
57
60

Outdoor IP65 50W 120LPW SMD3030 led security flood light 6
Outdoor IP65 50W 120LPW SMD3030 led security flood light 7
Outdoor IP65 50W 120LPW SMD3030 led security flood light 8
Outdoor IP65 50W 120LPW SMD3030 led security flood light 9Outdoor IP65 50W 120LPW SMD3030 led security flood light 10
Outdoor IP65 50W 120LPW SMD3030 led security flood light 11

Outdoor IP65 50W 120LPW SMD3030 led security flood light 12

Outdoor IP65 50W 120LPW SMD3030 led security flood light 13

Outdoor IP65 50W 120LPW SMD3030 led security flood light 14

Outdoor IP65 50W 120LPW SMD3030 led security flood light 15

Outdoor IP65 50W 120LPW SMD3030 led security flood light 16
Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-FL050-CGXX
3.6
355*350*165
4.5
1PCS/CTN
DR-FL100-CGXX
3.8
355*350*165
4.7
1PCS/CTN
DR-FL150-CGXX
4.5
415*410*175
5.8
1PCS/CTN
DR-FL200-CGXX
5.7
475*470*195
7.3
1PCS/CTN
DR-FL300-CGXX
9.3
475*470*195
11.5
1PCS/CTN



FAQ



Q1:What is a flood light?
RE:LED floodlights are lamps that specify that the illuminance on the illuminated surface is higher than the surrounding environment. Also called the spotlight. Normally, it can aim in any direction and has a structure that is not affected by weather conditions. It is mainly used for large-scale operation sites, general constructions, stadiums, overpasses, memorial monuments, parks and flower beds.

Floodlight (Floodlight), a floodlight is a point light source that can illuminate equally in all directions. Its illumination range can be adjusted arbitrarily, and it appears as a regular octahedron icon in the scene. Floodlights are the most common light source used in the production of function pictures. Standard floodlights are used to illuminate the entire scene.



Q2: What are the advantages of flood light?

RE:Advantages of LED flood light;

①High-purity aluminum reflector, the most accurate beam and the best reflection effect.

②Symmetrical narrow-angle, wide-angle and asymmetric light distribution systems.

③It is troublesome to change the light bulb with the open type behind.

④The lamps are equipped with a scale board to adjust the projection angle.

⑤It is suitable for lighting in large places and buildings.
