Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations

  • Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations
  • Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations
  • Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations
  • Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations
  • Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations
  • Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations
Product Details:
Place of Origin: Shenzhen,China
Brand Name: DUALRAYS
Certification: CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number: DR-HB100-EG2
Payment & Shipping Terms:
Minimum Order Quantity: 2PCS
Price: Negotiated
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 Bussiness Day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50000PCS/Month
Contact Now
Detailed Product Description
IP/Rating: IP65 Life Span: 50,000 Hours
Dimming Function: 1-10VDC /DALI / PIR Sensor PF: PF>0.95
Warranty: 5 Years CCT/K: 3000K-6500K
High Light:

led flat panel light fixture

,

wireless led outdoor flood lights

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations



Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 0
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 1



Dualrays HB5 Series UFO LED High Bay Light-- Data Sheet

Item No.
DR-HB100-EG2
Housing color
Silver, Black, Grey etc
Input Voltage
AC100-277V 50/60HZ
CRI
>80
Power
100W
IP Ranking
IP65
Working Temp
-40 to +50℃
Power Factor (PF)
>0.9
Lumen Output/Im
14,000
Light Source
SMD3030
Beam Angle
60°/90º/120º
LED Efficiency
150LPW
CCT
2700-6500K
Certificate
CE, RoHS,
Driving Brand
Meanwell/Sosen
Warranty
5 years

Dualrays HB5 Series UFO LED High Bay Light--Feature
* LUMILEDS LUXEON High Brightness SMD3030 LEDs,SOSEN;
* IP65 Protection;
* 60°/90°(with lens)/120°(without lens) beam angle optional;
* IP65 Protection;
* D-Mark tested for the use in paper production,wood processing etc with toughened glass;
* Multiple installations: loop hanging, ceiling mounting, wall mounting,pipe mounting;
* Various intelligent control: 1-10V, DALI, Motion sensor, Daylight sensor,Zigbee and Emergency;
* Customized supported for special projects;

Dualrays HB5 Series UFO LED High Bay Light--Options:
> Driver: Meanwell HBG(Round),ELG/HLG(Retangle),Sosen
> Controls and Dimming: Zigbee wireless control / 1-10V Dimming / Motion sensor / Emergency / DALI control / Daylight sensor.
> Reflector : PC reflector with / without cover.pipe mounting.
> Installation: loop hanging, ceiling mounting, wall mounting,
> Customized supported for special projects.

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 2
> Factories / Warehouses /Workshops
> Exhibitions & showrooms
> Barns and riding halls
> High rooms and halls
> Traditional lamp replacement


Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 3
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 4




Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 5

Character/Power
100W
150W
200W
240W
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 6
A
Ø350mm
Ø350mm
Ø420mm
Ø420mm
B
210mm
210mm
220mm
220mm


Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 7

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 8

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 9
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 10
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 11
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 12
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 13
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 14

DALI Device
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 15

DALI Intelligent Control Diagram
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 16 Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 17


DALI Intelligent Control Operator Interface
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 18

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 19
Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 20

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 21

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 22

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 23

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 24

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 25

Dualrays 100W HB5 Intellgent Control UFO High Bay Light IP65 Rating For Highway Toll Stations 26
Packaging Information
