| Place of Origin: | Shenzhen,China |
| Brand Name: | DUALRAYS |
| Certification: | CE,RoHS,TUV/GS,LM79,LM80 |
| Model Number: | DR-TPL050-BG5X |
| Minimum Order Quantity: | 8PCS |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Netural Package/OEM and ODM Package Available,10PCS/CNT |
| Delivery Time: | 5-15 business days |
| Supply Ability: | 100,000PCS/Month |
| IP/Rating: | IP65 | Warranty: | 5 Years |
|---|---|---|---|
| CCT/K: | 3000K-6500K | Stand-by Dimming: | 10% / 20% / 30% / 40% / 50%. |
| Beam Angle: | 120° | Times: | 100,000 |
| Highlight: | explosion proof led lights,vapor proof led light |
||
LED Tri Proof Light Feature:
Luminaire coated in an environmentally friendly polyester powder formulated in a silvery,black and white finish;
Suspended/Surface mounted/Adjustable installation for option;
Water-proof; Dust-proof; Damp-proof; Vapor-proof;
> Highly brightness EPISTAR/SAN‘AN SMD2835 LEDs,energy efficient - up to 160LPW;
> No UV or IR and completely mercury free;
> Plug : European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable optional.
| Item | Symbol | 2ft/20W | 4ft/40W | 5ft/50W |
| Model No | / | DR-TPL020-BG21 | DR-TPL040-BG41 | DR-TPL050-BG51 |
| Rated Power | W | 20 | 40 | 50 |
| LEDs Typ/Qty |
SMD 2835 |
144PCS | 273PCS | 312 PCS |
| Luminous Flux |
Clear Frost |
3,200±5% 3,000±5% |
6,400±5% 6,000±5% |
8,000±5% 7,500±5% |
| Efficiency |
Clear Frost |
Typ.160 Typ.150 |
Typ.160 Typ.150 |
Typ.160 Typ.150 |
| Lumen Maintenance @ 6000 hrs | Hours | >80% | ||
| Switching Cycle before Failure | Times | 100,000 | ||
| Life Span | Hours | 50,000 | ||
| Warranty | Years | 3 years | ||
| Operation Temperature | ℃ | -15 ~ +50℃ | ||
| Storage Temperature | ℃ | -25 ~ +55℃ | ||
|
Character/Length
|
2ft
|
4ft
|
5ft
|
|
|
A
|
600mm
|
1200mm
|
1500mm
|
|
|
B
|
74mm
|
74mm
|
74mm
|
|
|
C
|
74m
|
74mm
|
74mm
|
Q1: Is there MOQ requirement?
RE: No MOQ, Sample order for testing is welcome.
Q2: Can you do DIAlux Simulation?
RE: We have professional DIAlux team to support you, IES files also can be downloaded from our Website(www.dualrays.com).
Q3: Finished color?
RE: Standard colors: Black / White,other colors can be customized, based on MOQ 50PCS.
Q4: Can I have samples to test ?
RE: Yes,sure. Welcome to order samples for evaluation before bulk order.
Q5: LEDs are more expensive than other lighting options,why ?
RE: LEDs can operate as stand alone devices,but when grouped or clustered they require additional steps to operate properly. LEDs need proper components such as a circuits can be designed rapidly, but to ensure that they operate correctly and for long periods of time they require testing.
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
