    Product Details:

    Place of Origin: Shenzhen, China
    Brand Name: DUALRAYS
    Certification: CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
    Model Number: DR-HB100-EG2

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Price: Negotiable
    Packaging Details: Netural Package/OEM and ODM Package Available
    Delivery Time: 5-15 Bussiness Day
    Payment Terms: L/C, T/T, Western Union,Paypal
    Supply Ability: 50000PCS/Month
    Contact Now
    Detailed Product Description
    Rated Power: 100W Dimming: 1-10W
    Beam Angle: 60°/90°(with Lens)/120°(without Lens) Warranty: 5 Years
    Driving Brand: Meanwell/Sosen
    High Light:

    led flat panel light fixture

    ,

    high bay led shop lights

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65



    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 0
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 1



    Dualrays 100W HB5 Series UFO LED High Bay Light-- Data Sheet

    Item No.
    DR-HB150-EG2
    Driving Brand
    Meanwell/Sosen
    Input Voltage
    AC100-277V 50/60HZ
    CRI
    >80
    Power
    150W
    IP Ranking
    IP65
    Warranty
    5 Years
    Power Factor (PF)
    >0.9
    LED QTY
    194PCS
    Light Source
    SMD3030
    Beam Angle
    60°/120º
    LED Efficiency
    160LPW
    CCT
    2700-6500K
    Certificate
    CE, RoHS

    Dualrays 100W HB5 Series UFO LED High Bay Light--Feature
    > Highly brightness LUXEON SMD3030 LEDs,energy efficient - up to 160 lm/w;
    > Die-casting Al for excellent heat dissipation;
    > Superior PC reflector-optic for low glare applications,PMMA,glass cover available;
    > IP65 and IK10 for all industrial areas of application;
    > Driver and housing separated by spacers;
    > Adjustable ripple-lens optic with 60°/90°/120° beam angle;
    > D-Mark tested for the use in paper production, wood processing etc;
    > No UV or IR and completely mercury free;
    > L80/B10 @ 50.000h;
    > 5 years warranty;

    Dualrays 100W HB5 Series UFO LED High Bay Light--Options:
    > Driver: Meanwell HBG(Round),ELG/HLG(Retangle),Sosen
    > Controls and Dimming
    ·Zigbee wireless control / 1-10V Dimming / Motion sensor / Emergency / DALI control / Daylight sensor.
    > Reflector : PC reflector with / without cover.pipe mounting.
    > Installation: loop hanging, ceiling mounting, wall mounting,
    > Customized supported for special projects.

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 2
    > Factories / Warehouses /Workshops
    > Exhibitions & showrooms
    > Barns and riding halls
    > High rooms and halls
    > Traditional lamp replacement


    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 3
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 4



    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 5

    Character/Power
    100W
    150W
    200W
    240W
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 6
    A
    Ø350mm
    Ø350mm
    Ø420mm
    Ø420mm
    B
    210mm
    210mm
    220mm
    220mm


    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 7

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 8

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 9
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 10
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 11
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 12
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 13
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 14

    DALI Device
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 15

    DALI Intelligent Control Diagram
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 16 Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 17


    DALI Intelligent Control Operator Interface
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 18

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 19
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 20

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 21

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 22

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 23

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 24

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 25

    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 26
    Packaging Information
    Dualrays 100W HB5 Multiple Dimming Warehouse Industrial LED High Bay 160 lmw High Efficiency IP65 27
