100W LED Sports Ground Football Processional Optics Design For Public Ground Display

100W LED Sports Ground Football Processional Optics Design For Public Ground Display

  • 100W LED Sports Ground Football Processional Optics Design For Public Ground Display
  • 100W LED Sports Ground Football Processional Optics Design For Public Ground Display
  • 100W LED Sports Ground Football Processional Optics Design For Public Ground Display
  • 100W LED Sports Ground Football Processional Optics Design For Public Ground Display
100W LED Sports Ground Football Processional Optics Design For Public Ground Display
Product Details:
Place of Origin: Shenzhen,China
Brand Name: DUALRAYS
Certification: CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number: DR-FL100-CGXP
Payment & Shipping Terms:
Minimum Order Quantity: 2PCS
Price: Negotiable
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 Bussiness Day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000PCS/Month
Contact Now
Detailed Product Description
Rated Power: 100 Luminaire Efficiency: 140lm/W
Power Factor: PF>0.9 Lumen Maintenance @ 6000 Hrs: >90%
Switching Cycle Before Failure: 100,000 Metarial: AL+PC
High Light:

industrial high bay led lighting

,

high mast flood lights

100W LED Sports Ground Football Processional Optics Design For Public Ground Display

Why choosing DUALRAYS:



* Professional team: >10 years experience, own factory, >10 engineers team, powerful production capacity and QC management system, provide both good quality product and service;

* Reliable brand: Built up stable and long-term cooperation with Europe customers, got high prise and trust, and have warehouse in Netherlands for better service;

* Provide DIALux simulation: Send us your parameters of the applications, like distance, height, width, etc, our engineer team will do simulation according to your demand and recommend you the best product;

* All our LED luminaries comply with CE, RoHS standard. TUV, ENEC, VDE, SAA,C-Tick, LM79,LM80 listed for the leading products.

Factory suupply SMD 3030 Modular LED Flood Light 120 ° Beam Angle For Ground / Stadium

Model NO. DR-FL100-CGXP
CCT/K 3000-6500K
CRI(Ra) >70Ra(>80Ra for option)
LEDs Lights Source SMD3030
Input Voltage(V) AC 100~277 V 50/60 Hz
Metarial Aluminums + PC
Dimming 0/1~10V /PWM/ Zigbee
> Efficient - up to 150LPW;
> Die-casting Al for excellent heat dissipation;
> IP66 and IK10 for all industrial areas of application;
> Driver and housing separated by spacers;
> 10°/25°/45°/60°/90°/130*30°polarized light 60° beam angle optional;
> D-Mark tested for the use in paper production, wood processing etc;
Factory suupply SMD 3030 Modular LED Flood Light 120 ° Beam Angle For Ground / Stadium
> Airport Hall,Exhibition Hall
> Building exterior lighting
> Warehouse, Factory, stair corridors lighting
> Large and small parking, Square, Stadium lighting etc
> Bridges and public places, as well as other industrial and commercial lighting
> Gardens lighting
Factory suupply SMD 3030 Modular LED Flood Light 120 ° Beam Angle For Ground / Stadium
IP Rating IP65
Power Factor PF>0.95
Starting Time <0.1
LED Driver Meanwell
Life Span/hrs >50000
Warranty 5 years
Operation Temperature -40 ~ +55℃

Outdoor IP65 50W 120LPW SMD3030 led security flood light 0
Outdoor IP65 50W 120LPW SMD3030 led security flood light 1

Options:
> Driver: Sosen,Meanwell ELG/HLG driver;
> Controls and Dimming: 1-10V, DALI,PWM,Zigbee;
> Surge Protection Device: Meanwell SPD-20 20KV Surge Protector;
> Lens : Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV;
> Microwave Motion Sensor;

Outdoor IP65 50W 120LPW SMD3030 led security flood light 2
> Airports & Harbors
> Billboard illumination
> Large recreational sports facilities
> Industrial areas & Landscape buildings
> Roundabouts and motorway junctions

Outdoor IP65 50W 120LPW SMD3030 led security flood light 3
Model No.
DR-FL050-CGXX DR-FL100-CGXX DR-FL150-CGXX DR-FL200-CGXX DR-FL300-CGXX
System Watts/W
50W 100W 150W 200W
300W
System Efficiency/LPW
120~125LPW
Lumen Output/lm
6.500±5% 12.500±5% 18.750±5% 25.000±5% 37.500±5%
Rated Input Voltage/V
AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
LEDs Light Source
SMD3030
SDCM
<5
CCT/K
5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra
>70Ra (>80Ra for Option)
Power Factor
>0.95
THD
<10%
Beam Angle(Optional)
Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV beam angle optional
UGR
<25
Surge Protection
6~10KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver
Sosen,Meanwell ELG / HLG Optional
IP Rating
IP65
Dimming(Optional)
1-10V, DALI,PWM,Zigbee for Option
Safety Protection Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Sensor (Optional) Motion Sensor
Protection Class
ClassⅠ
Finishing Color(Optional)
Black RAL9017(Standard) / White RAL9016 Optional
Material
Aluminum+Toughened Glass
Lifespan/hrs
62.000 Hrs (Ta=30℃@L70)
Operation Temp/℃
40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃
- 40°C to + 65°C(-40°F to 149°F)
Switching Cycles 100,000 Times
Certificate
CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

Outdoor IP65 50W 120LPW SMD3030 led security flood light 4
Character/Power
100W
150W
200W
240W
300W
Outdoor IP65 50W 120LPW SMD3030 led security flood light 5
A / mm
389
389
437
493
582
B / mm
297
297
346
379
444
C / mm
57
57
57
57
60

Outdoor IP65 50W 120LPW SMD3030 led security flood light 6
Outdoor IP65 50W 120LPW SMD3030 led security flood light 7
Outdoor IP65 50W 120LPW SMD3030 led security flood light 8
Outdoor IP65 50W 120LPW SMD3030 led security flood light 9Outdoor IP65 50W 120LPW SMD3030 led security flood light 10
Outdoor IP65 50W 120LPW SMD3030 led security flood light 11

Outdoor IP65 50W 120LPW SMD3030 led security flood light 12

Outdoor IP65 50W 120LPW SMD3030 led security flood light 13

Outdoor IP65 50W 120LPW SMD3030 led security flood light 14

Outdoor IP65 50W 120LPW SMD3030 led security flood light 15

Outdoor IP65 50W 120LPW SMD3030 led security flood light 16
Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-FL050-CGXX
3.6
355*350*165
4.5
1PCS/CTN
DR-FL100-CGXX
3.8
355*350*165
4.7
1PCS/CTN
DR-FL150-CGXX
4.5
415*410*175
5.8
1PCS/CTN
DR-FL200-CGXX
5.7
475*470*195
7.3
1PCS/CTN
DR-FL300-CGXX
9.3
475*470*195
11.5
1PCS/CTN



FAQ



Q1:What is a flood light?
RE:LED floodlights are lamps that specify that the illuminance on the illuminated surface is higher than the surrounding environment. Also called the spotlight. Normally, it can aim in any direction and has a structure that is not affected by weather conditions. It is mainly used for large-scale operation sites, general constructions, stadiums, overpasses, memorial monuments, parks and flower beds.

Floodlight (Floodlight), a floodlight is a point light source that can illuminate equally in all directions. Its illumination range can be adjusted arbitrarily, and it appears as a regular octahedron icon in the scene. Floodlights are the most common light source used in the production of function pictures. Standard floodlights are used to illuminate the entire scene.



Q2: What are the advantages of flood light?

RE:Advantages of LED flood light;

①High-purity aluminum reflector, the most accurate beam and the best reflection effect.

②Symmetrical narrow-angle, wide-angle and asymmetric light distribution systems.

③It is troublesome to change the light bulb with the open type behind.

④The lamps are equipped with a scale board to adjust the projection angle.

⑤It is suitable for lighting in large places and buildings.
