Home ProductsLED High Mast Light

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency

  • Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency
  • Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency
Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency
Product Details:
Place of Origin: Shenzhen,China
Brand Name: DUALRAYS/OEM
Certification: CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Model Number: DR-FL200-EG2
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: Negotaited
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 Bussiness Day
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50000PCS/Month
Contact Now
Detailed Product Description
Material: Aluminium Alloy +PC Input Voltage: AC100~277V 50/60Hz
Power: 200W CCT: 3000/4000/5000/5700K±200K
Efficiency: 150LPW Power Factor: >0.95
Power Efficiency: >92% Guarantee: 5 Years
High Light:

led stadium floodlights

,

wireless led outdoor flood lights

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 0
Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 1

Options:
> Driver: Sosen,Meanwell ELG/HLG driver;
> Controls and Dimming: 1-10V, DALI,PWM,Zigbee;
> Surge Protection Device: Meanwell SPD-20 20KV Surge Protector;
> Lens : Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV;
> Microwave Motion Sensor;

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 2
> Airports & Harbors
> Billboard illumination
> Large recreational sports facilities
> Industrial areas & Landscape buildings
> Roundabouts and motorway junctions

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 3
Model No.
DR-FL050-CGXX DR-FL100-CGXX DR-FL150-CGXX DR-FL200-CGXX DR-FL300-CGXX
System Watts/W
50W 100W 150W 200W
300W
System Efficiency/LPW
120~125LPW
Lumen Output/lm
6.500±5% 12.500±5% 18.750±5% 25.000±5% 37.500±5%
Rated Input Voltage/V
AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
LEDs Light Source
SMD3030
SDCM
<5
CCT/K
5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra
>70Ra (>80Ra for Option)
Power Factor
>0.95
THD
<10%
Beam Angle(Optional)
Symmetrical 30°/60°/90°/120°,Asymmetrical/Type II / Type III / Type IV beam angle optional
UGR
<25
Surge Protection
6~10KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver
Sosen,Meanwell ELG / HLG Optional
IP Rating
IP65
Dimming(Optional)
1-10V, DALI,PWM,Zigbee for Option
Safety Protection Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Sensor (Optional) Motion Sensor
Protection Class
ClassⅠ
Finishing Color(Optional)
Black RAL9017(Standard) / White RAL9016 Optional
Material
Aluminum+Toughened Glass
Lifespan/hrs
62.000 Hrs (Ta=30℃@L70)
Operation Temp/℃
40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃
- 40°C to + 65°C(-40°F to 149°F)
Switching Cycles 100,000 Times
Certificate
CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 4
Character/Power
100W
150W
200W
240W
300W
Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 5
A / mm
389
389
437
493
582
B / mm
297
297
346
379
444
C / mm
57
57
57
57
60

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 6
Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 7
Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 8
Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 9Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 10
Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 11

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 12

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 13

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 14

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 15

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 16
Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-FL050-CGXX
3.6
355*350*165
4.5
1PCS/CTN
DR-FL100-CGXX
3.8
355*350*165
4.7
1PCS/CTN
DR-FL150-CGXX
4.5
415*410*175
5.8
1PCS/CTN
DR-FL200-CGXX
5.7
475*470*195
7.3
1PCS/CTN
DR-FL300-CGXX
9.3
475*470*195
11.5
1PCS/CTN

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 17
Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 18

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 19

Outdoor Soccer Field LED Stadium Floodlights Playground Lighting 200W 150LPW Efficiency 20
