| Place of Origin: | Shenzhen,China |
| Brand Name: | DUALRAYS/OEM |
| Certification: | CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available |
| Model Number: | DR-FL500-EGXP |
| Minimum Order Quantity: | 1PCS |
|---|---|
| Price: | Please inquiry for latest price |
| Packaging Details: | Netural Package/OEM and ODM Package Available |
| Delivery Time: | 5-15 Bussiness Day |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 50000PCS/Month |
| Power Factor: | >0.92 | Luminous Flux: | 75.000lm±5% |
|---|---|---|---|
| IP Rating: | IP66 | Material: | Aluminium Alloy +PC |
| Surge Protection: | 6~10KV SPD Driver,Exterior SPD 10KV() Or 20KV Meanwell Optional | Beam Angle: | 10°/25°/45°/60°/90°/130*30 Polarized Light 60° |
| Installation(Optional): | Ground Mounting, Wall Mounting, Ceiling Mounting,Pipe Mounting | Certificate: | CE(EMC+LVD),RoHS,TUV/GS ,D-Mark,SAA,RCM Available |
| High Light: | led stadium floodlights,led tennis court lights |
||
| Model No. | DR-FL500-EGXP | ||||||
| System Watts/W | 500W | ||||||
| System Efficiency/LPW | 150LPW | ||||||
| Lumen Output/lm | 75.000±5% | ||||||
| Dimming(Optional) | 0/1-10V/PWM/DALI/Zigbee | ||||||
| Installation(Optional) | Ground Mounting, Wall Mounting, Ceiling Mounting,Pipe Mounting | ||||||
| Certificate | CE(EMC+LVD),RoHS,D-Mark,SAA,RCM Available | ||||||
| Finishing Color(Optional) | Black RAL9017 / White RAL9016 | ||||||
| Protection Class | ClassⅠ | ||||||
| LED Driver | Meanwell XLG/ELG/HLG,Sosen | ||||||
| Surge Protection | 6~10KV SPD Driver,Exterior SPD 10KV() or 20KV Meanwell Optional | ||||||
| Rated Input Voltage/V | AC100~277V 50/60Hz | ||||||
| LEDs Light Source | SMD3030 | ||||||
| SDCM | <6 | ||||||
| CCT/K | 3000K/4000K/5000K/5700K/6500K | ||||||
| Lifespan/hrs | >50.000 Hrs (Ta=30 @L70) | ||||||
| Operation Temp/℃ | -40°C to + 50°C(-40°F to 122°F) | ||||||
| Installation(Optional) | Ground Mounting, Wall Mounting, Ceiling Mounting,Pipe Mounting | ||||||
| Certificate | CE(EMC+LVD),RoHS,D-Mark,SAA,RCM Available | ||||||
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
