IP 65 CE CB ASS TUV Support Any Special Project 180W LED Street Lights With Motion Sensor For Highway

IP 65 CE CB ASS TUV Support Any Special Project 180W LED Street Lights With Motion Sensor For Highway

  • IP 65 CE CB ASS TUV Support Any Special Project 180W LED Street Lights With Motion Sensor For Highway
  • IP 65 CE CB ASS TUV Support Any Special Project 180W LED Street Lights With Motion Sensor For Highway
  • IP 65 CE CB ASS TUV Support Any Special Project 180W LED Street Lights With Motion Sensor For Highway
  • IP 65 CE CB ASS TUV Support Any Special Project 180W LED Street Lights With Motion Sensor For Highway
IP 65 CE CB ASS TUV Support Any Special Project 180W LED Street Lights With Motion Sensor For Highway
Product Details:
Place of Origin: Shenzhen,China
Brand Name: Dualrays
Certification: CE,RoHS,LM79,LM80
Model Number: DR-ST180-DGXP
Payment & Shipping Terms:
Minimum Order Quantity: 2PCS
Price: Negotiable
Packaging Details: Netural Package/OEM and ODM Package Available
Delivery Time: 5-15 Bussiness Day
Payment Terms: Western Union, T/T, L/C,Paypal
Supply Ability: 100000PCS/Month
Contact Now
Detailed Product Description
Material: Aluminum Operation Temperature: -40℃~50℃
Life Span: >50,000 Power Supply: Meanwell/Sosen
Input Voltage: AC100~277V 50/60Hz Dimming Function: 0/1-10V DALI/Zigbee
High Light:

led cobra head street light

,

decorative street light

IP 65 CE CB ASS TUV Support Any Special Project 180W LED Street Lights With Motion Sensor For Highway



* Processional optics design,Type III Medium(90°x140°),Type III Short 90°x120°,Type V 120°,Type II 80°x135° for option;
* Top brand conponents,NICHINA LEDs light source,Meanwell driver,durable;
* Modular design optimizes construction and assembly, allows for easy maintenance, upgrade and SKD purchasing for local assembly;
* Tool-less access to the down-opening driver door makes easy maintenance and operation;
* Multi beam angle for different occassions;
* Intelligent dimming control available,photocell controller is available;
* Maintenance Free,IP66 protection,IK10 vibration grade;
* 10KV/20KV SPD for option;
* LM-79/80 reports available;
* CE,RoHS listed,5 years’ warranty.


Why choosing DUALRAYS:



* Professional team: >10 years experience, own factory, >10 engineers team, powerful production capacity and QC management system, provide both good quality product and service;

* Reliable brand: Built up stable and long-term cooperation with Europe customers, got high prise and trust, and have warehouse in Netherlands for better service;

* Provide DIALux simulation: Send us your parameters of the applications, like distance, height, width, etc, our engineer team will do simulation according to your demand and recommend you the best product;

* All our LED luminaries comply with CE, RoHS standard. TUV, ENEC, VDE, SAA,C-Tick, LM79,LM80 listed for the leading products.

2020 Top sae Heat Dissipation Cobra Led Street Light IK10 Vibration Grade 180W 10KV / 20KV SPD IP66 with motion sensor

2020 Hot sale Outpt street led lights with motion serson for highway display

Outdoor LED Street Lights Production sepecification:

> High brightness LUXEON SMD3030 LEDs,energy efficient - up to 150 lm/w;
> Die-casting Al for excellent heat dissipation;
> Superior PC reflector-optic for low glare applications,and toughened glass protection;
> IP66 and IK10 for road lighting application;
> Driver and housing separated by spacers;
> Professional 50(V)*120(H)°/75(V)*150°(H) optic for option;
> ±10°/-90°(<90W) or ±15°/-90°(>90W) lamp head adjustable;
> No UV or IR and completely mercury free;
> L80/B10 @ 50.000h;
> Controls and Dimming: 1-10V, DALI, PWM,Zigbee Wireless Dimming for option;
> 10KA SPD,20KA Meanwell SPD optional;
> 3-pins photocell controller ON/OFF,and 7-pins LORA/NEMA socket smart wireless control available;
> Zigbee module (Single-lamp Controller and centralized manager) with software for option;
> DALI driver and DALI Centralized Manager optional;
> Light pole adapter for different poles optional;
> Customized supported for special projects;
2020 Hot sale Outpt street led lights with motion serson for highway display
* Roadways.
* Avenues.
* Walkways.
* Loading Area.
* Parking lot.
* Playground.
* Sport and Stadium.
SMD IP66 Waterproof Outdoor LED Street Lights Aluminium Alloy 90W 120W 150W 180W
Item No.
DR-ST60-DGXP
Housing color
Silver, Black, Grey etc
Input Voltage
AC100-277V 50/60HZ
CRI
>80Ra(>70Ra for option)
Power
180W
IP Rating
IP66
Working Temp
-40 to +50℃
IK Rating
IK10
Luminous Flux
16,800lm
Material
AL+PMMA
Beam Angle
60*120º/75*135°
LED Efficiency
150LPW
CCT
2700-6500K
Certificate
CE, RoHS,
Dimension
950(L)*455(W)*125(D)mm
Warranty
5 years
UGR
<25
Driving Brand
Meanwell/Sosen
2020 Hot sale Outpt street led lights with motion serson for highway display
30W/60W Version
2020 Hot sale Outpt street led lights with motion serson for highway display
90W,120W/150W/180W Version
2020 Hot sale Outpt street led lights with motion serson for highway display

2020 Hot sale Outpt street led lights with motion serson for highway display
2020 Hot sale Outpt street led lights with motion serson for highway display

2020 Hot sale Outpt street led lights with motion serson for highway display
2020 Hot sale Outpt street led lights with motion serson for highway display
2020 Hot sale Outpt street led lights with motion serson for highway display2020 Hot sale Outpt street led lights with motion serson for highway display2020 Hot sale Outpt street led lights with motion serson for highway display2020 Hot sale Outpt street led lights with motion serson for highway display
2020 Hot sale Outpt street led lights with motion serson for highway display
Zigbee Wireless Intelligent Control Operator Interface

2020 Hot sale Outpt street led lights with motion serson for highway display



IP66 150W Recessed Retrofit LED Canopy Light For Gas Station

IP66 150W Recessed Retrofit LED Canopy Light For Gas Station

IP66 150W Recessed Retrofit LED Canopy Light For Gas Station

We are proud to provide innovative designs,affordable LED luminaires,high-touch service, excellent customer experience for the leading distributor,wholesaler,and contractor from Western Europe and Oceania.

1

In addition,we can provide our customers value added service with Dialux software for lighting design projects free of charge.

5                                                                                               (Partnership)

          Dualrays adheres to independent innovation, Dualraysers try to build a world well-known LED industrial Lighting Brand.

2

                                                                                            (Customer Portfolio)

                                          Dualrays is practicing the enterprise management principle “Perfect or Nothing”.

6






140LPW Efficiency Led Outside Flood Lights 60W  LED Source Multi Beam Angle
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!2020 Hot sale Outpt street led lights with motion serson for highway display
